Build thread-55

I guess this will be my build thread. Got the truck mostly assembled, but having to tear it down to fix previous owners horrible work.

Loading the 55 to drive it 800 miles
Name:  image_zpsd6e598de.jpg
Views: 439
Size:  114.5 KB

Here she sits in my garage. Starting to dis assemble and get a closer look

Name:  truck.jpg
Views: 451
Size:  103.8 KB

You'll notice no strut rods and no shocks on mustang II front end

Name:  image_zps256406e7.jpg
Views: 446
Size:  107.4 KB


Besides media blasting rear and front fenders, first real work done on the truck was today 2/9/13. The stock 74 mustang II crossmember was cold welded and installed backwards. Special thanks goes out to Garbz and Bill W for the help. Learned a lot today and look forward to learning so much

Saw zaw and angle grinder and most of the crossmember was out. Bill W goin to town on the BFH!!!!
Name:  image_zpsd8920b8e.jpg
Views: 445
Size:  94.1 KB

Grinding it down and making it smooth
Name:  image_zpsd73d8eb7.jpg
Views: 438
Size:  95.0 KB

Forgot to say make sure everything is balanced before any welds.
Name:  image_zps8378f009.jpg
Views: 436
Size:  92.2 KB

Marked centerline and tack welded.

Name:  image_zpsd73d8eb7.jpg
Views: 438
Size:  95.0 KB

Name:  image_zps6cdbbc33.jpg
Views: 441
Size:  77.4 KB

Garbz welded in crossmember. During the weld, old boxing plates weld cracked all the way down the frame..

Name:  image_zpsbc13baca.jpg
Views: 439
Size:  79.6 KB

Name:  image_zps41c37fca.jpg
Views: 438
Size:  101.3 KB

Nice welds Garbz!!( I actually made 3 tack welds today



Name:  image_zpsbe36e660.jpg
Views: 438
Size:  78.9 KB

To be continued... Tomorrow replace control arm bushings and ball joints. Originals since 1974. Install shocks and rest of front suspension. I guess I'll just post pics as I go?
