Oct 12, 2022 | 08:53 AM

#16

RacinJasonWV

Lead Driver

Joined: Jul 2017

Posts: 6,853

Likes: 2,331

From: WV

Quote:

Originally Posted by Hyakkimaru

Where did you buy the plastic plug? I'm sure a rubber plug would work just as good. Auto parts? My games are going to be here tomorrow so, I might tackle that job tomorrow afternoon after work if I can.

Sorry, there’s a factory plastic plug in mine at this location. I went through there instead of drilling the firewall. Seems like I put it towards the side so the hole could be smaller and run a slit to the edge to slide the wires/lines through.

Oct 12, 2022 | 10:52 AM

#17

Hyakkimaru

Thread Starter

Logistics Pro

Joined: Jan 2021

Posts: 4,077

Likes: 1,143

From: Fairhope Alabama

Quote:

Originally Posted by RacinJasonWV

I'll have to look at mine this afternoon. I think I read somewhere that the factory customer access wires that are under the dash they also come out right behind the fuse box have a plug right there somewhere that they go through the firewall at. I also read some people put a little slit in the steering column exit point where the steering shaft exit the cab. I'll have to look into it this afternoon. My gauges are supposed to be here today so, I better figure it out quick LOL

Oct 12, 2022 | 06:44 PM

#18

Hyakkimaru

Thread Starter

Logistics Pro

Joined: Jan 2021

Posts: 4,077

Likes: 1,143

From: Fairhope Alabama

There are no available grommets on the firewall. I'm going to have to drill a hole because the only girl and I know that would have been there would be the clutch master cylinder. I'm thinking of grilling my hole right next to the steering shaft over by about 2 in towards the driver side.

Oct 12, 2022 | 09:10 PM

#19

RacinJasonWV

Lead Driver

Joined: Jul 2017

Posts: 6,853

Likes: 2,331

From: WV

The plug I was talking about is probably for the clutch (that I don’t have). By memory I was thinking it was too far towards the side to be that but now I’d say my memory is wrong.

Oct 13, 2022 | 12:40 AM

#20

Y2KW57

Super Moderator

Joined: Dec 2011

Posts: 13,283

Likes: 6,047

Quote:

Originally Posted by Hyakkimaru

Have you located the Customer Access circuits on your truck yet?

What type of circuit related to "Hydra location" are you wanting to run through the firewall?

Oct 13, 2022 | 07:22 AM

#21

Hyakkimaru

Thread Starter

Logistics Pro

Joined: Jan 2021

Posts: 4,077

Likes: 1,143

From: Fairhope Alabama

Quote:

Originally Posted by Y2KW57

Have you located the Customer Access circuits on your truck yet?

What type of circuit related to "Hydra location" are you wanting to run through the firewall?

Nothing that is related to the hydra. It was just a side note because my gauges were on their way and I was wondering where my wires were going to poke through the firewall for the gauges. My bad, should have made another thread for the gauges.

Oct 13, 2022 | 11:45 AM

#22

FordTruckNoob

FTE Chapter Leader

Joined: Jan 2005

Posts: 13,096

Likes: 4,705

From: Henderson, NV

Quote:

Originally Posted by Hyakkimaru

Go old school and mount the gauges outside on the cowl. No holes required.

Adding a ramcharger would be pretty badass too.

Oct 13, 2022 | 12:01 PM

#23

SkySkiJason

Hotshot

Joined: Jul 2008

Posts: 12,782

Likes: 2,142

From: N.GA Mountains

You’ll want to drill a hole and use a grommet for the gauge wires.

I run the fuel pressure and boost sensor wires together in wire loom up behind the plastic wire tray at the rear of hood opening. Add another 14-16ga wire and you can install a GP indicator light in your gauge pod.

FTE Stories

Ford Trucks for Ford Truck Enthusiasts

Top 10 Ford Truck Tragedies

Joe Kucinski

AEV FXL Super Duty - the Super Duty Raptor Ford Doesn't Make

Brett Foote

Lobo Vs Lobo: Proof the F-150 Lobo Should Be Even Lower!

Michael S. Palmer

Ford's 2001 Explorer Sportsman Concept Looks For a New Home

Verdad Gallardo

10 Best Ford Truck Engines We Miss the Most!

Joe Kucinski

2026 Shelby F-150 Off-Road: Better Than a Raptor R?

Brett Foote

2027 Super Duty Carhartt Package First Look: 12 Things You NEED to Know!

Michael S. Palmer

10 Most Surprising 2026 Ford Truck Features!

Joe Kucinski

Top 10 Ford Trucks Coming to Mecum Indy 2026

Brett Foote

5 Best / 5 Worst Ford Truck Wheels of All Time

Joe Kucinski

Oct 13, 2022 | 12:37 PM

#24

Hyakkimaru

Thread Starter

Logistics Pro

Joined: Jan 2021

Posts: 4,077

Likes: 1,143

From: Fairhope Alabama

Quote:

Originally Posted by SkySkiJason

I stayed up till 10:00 last night after work installing my gauges. I ran everything the same way you just described. I'll post a picture of my grommet later on. I still got to figure out what I'm going to do with all the extra wire I have. the EGT wire was a couple foot too long and the fuel pressure sensor wire was a few foot too long. I can cut the boost to the links but the other stuff cannot be cut. Not easily anyway. I also did run a glow plug led a couple months ago. I'll post pictures of everything this afternoon!

Oct 13, 2022 | 06:02 PM

#25

Tpayne621

Cargo Master

Joined: Apr 2022

Posts: 3,191

Likes: 1,696

Fold up all the excess and tie up under dash or in corner under hood near computer neatly.

Oct 13, 2022 | 08:47 PM

#26

RacinJasonWV

Lead Driver

Joined: Jul 2017

Posts: 6,853

Likes: 2,331

From: WV

Quote:

Originally Posted by Tpayne621

Fold up all the excess and tie up under dash or in corner under hood near computer neatly.

⬆️ This.

I usually roll the excess in loops and zip tie it up under the dash.

We
want
photos

Oct 13, 2022 | 09:19 PM

#27

SkySkiJason

Hotshot

Joined: Jul 2008

Posts: 12,782

Likes: 2,142

From: N.GA Mountains

I start at the senders and trim the wires at the gauges. No ‘extra’.

Oct 13, 2022 | 10:54 PM

#28

Hyakkimaru

Thread Starter

Logistics Pro

Joined: Jan 2021

Posts: 4,077

Likes: 1,143

From: Fairhope Alabama

Quote:

Originally Posted by SkySkiJason

I start at the senders and trim the wires at the gauges. No ‘extra’.

These glow shift gauges have connectors, with heat shrink all the way down the the wires. I don't really want to cut and splice wires to try to get it to the length I want. I'd rather roll the wire up and zip tie it. I haven't cleaned up the wiring under the dash yet, but I did make a little video of the gauges and the wiring under the hood. Don't mind the welding in the background.... It's not being done on my truck. It's being done on my trailer. Putting new, bigger chains.

Oct 14, 2022 | 03:32 AM

#29

cleatus12r

Butt-Head

Joined: Apr 2004

Posts: 9,419

Likes: 2,912

From: Reed Point, MT

You're probably going to want to find a t-bolt clamp for that charge air pipe before too long. I'm surprised you haven't blown that aftermarket hose connector off yet.

Oct 14, 2022 | 06:49 AM

#30

RacinJasonWV

Lead Driver

Joined: Jul 2017

Posts: 6,853

Likes: 2,331

From: WV

Quote:

Originally Posted by cleatus12r

You're probably going to want to find a t-bolt clamp for that charge air pipe before too long. I'm surprised you haven't blown that aftermarket hose connector off yet.

Oh but I believe he has…a couple of times.

Ok, in all fairness I think it was the on the pipe side and with the original boot. But too funny not to poke about it.
