Oil Temp Warning

  #1
Old 08-06-2018, 11:29 AM
ajp207
ajp207 is offline
New User
Thread Starter
Join Date: Aug 2018
Posts: 3
ajp207 is starting off with a positive reputation.
Oil Temp Warning

Ok, so my 2016 F350 6.7 is my first diesel. While going over mountains in Colorado my oil temp was in the 240 range. I came to a construction stop and without thinking I turned the engine off without idling to get the temp lower. When I was given the ok to continue and started the engine the oil temp gauge was buried and the red engine oil warning light came on. It quickly came off after about 20 seconds of running. My question is, did I damage the oil in any manner i.e. did it boil the oil, should I replace the oil, (currently about 2000 miles since last oil change) Any help appreciated.

  #2
Old 08-06-2018, 11:33 AM
Iowa Ford's Avatar
Iowa Ford
Iowa Ford is offline
Post Fiend
Join Date: Mar 2013
Location: EC Iowa
Posts: 5,338
Iowa Ford has a superb reputationIowa Ford has a superb reputationIowa Ford has a superb reputationIowa Ford has a superb reputationIowa Ford has a superb reputationIowa Ford has a superb reputationIowa Ford has a superb reputationIowa Ford has a superb reputationIowa Ford has a superb reputationIowa Ford has a superb reputationIowa Ford has a superb reputation
I would say don't make a habit of doing that and you will be fine.

  #3
Old 08-06-2018, 12:34 PM
99150's Avatar
99150
99150 is offline
Postmaster
Join Date: Oct 2006
Location: AZ
Posts: 3,393
99150 has a superb reputation99150 has a superb reputation99150 has a superb reputation99150 has a superb reputation99150 has a superb reputation99150 has a superb reputation99150 has a superb reputation99150 has a superb reputation99150 has a superb reputation99150 has a superb reputation99150 has a superb reputation
Originally Posted by ajp207 View Post
Ok, so my 2016 F350 6.7 is my first diesel. While going over mountains in Colorado my oil temp was in the 240 range. I came to a construction stop and without thinking I turned the engine off without idling to get the temp lower. When I was given the ok to continue and started the engine the oil temp gauge was buried and the red engine oil warning light came on. It quickly came off after about 20 seconds of running. My question is, did I damage the oil in any manner i.e. did it boil the oil, should I replace the oil, (currently about 2000 miles since last oil change) Any help appreciated.
Being a new diesel owner, you want to stop that “without thinking”!! LOL. But all humor aside, I have read that phrase many times.......without thinking I put gas in the fuel tank........without thinking I put DEF in the fuel tank, etc. It seems to be one of the major causes of expensive repair bills.
Yes, on any engine.....gas or diesel.....I like to give them a few minutes after a hard pull to let things cool down a bit.
But, if everything returned to normal shortly after re-starting the engine, you are probably good to go.
Enjoy the smooth power of the PowerStroke!!

  #4
Old 08-06-2018, 04:33 PM
The Bone's Avatar
The Bone
The Bone is offline
Elder User
Join Date: Feb 2015
Posts: 717
The Bone has a good reputation on FTE.The Bone has a good reputation on FTE.
I also let mine cool down before shutting it off. I do a lot of traveling with my 5th wheel and never shut it off when fueling. It's funny how much thinking you have to do when owning a diesel. You have to wait till the glow plug light goes off before starting the engine. Then wait till it cools down to normal operating temp before shutting it off. I only use synthetic oil because it works better under extreme conditions better than the blend. The blend doesn't mean a 50/50 ether. Not sure how much synthetic oil that they can use to call it a blend. Doesn't say on the can.

  #5
Old 08-06-2018, 06:48 PM
senix's Avatar
senix
senix is offline
Moderator
Join Date: Aug 2008
Location: Frederick, MD
Posts: 29,118
senix has a superb reputationsenix has a superb reputationsenix has a superb reputationsenix has a superb reputationsenix has a superb reputationsenix has a superb reputationsenix has a superb reputationsenix has a superb reputationsenix has a superb reputationsenix has a superb reputationsenix has a superb reputation
Turbo's are the issue here. hot oil means no lube on the bearings.

  #6
Old 08-06-2018, 09:11 PM
Painted Horse's Avatar
Painted Horse
Painted Horse is online now
Postmaster
Join Date: Nov 2005
Posts: 2,548
Painted Horse has a brilliant futurePainted Horse has a brilliant futurePainted Horse has a brilliant futurePainted Horse has a brilliant futurePainted Horse has a brilliant futurePainted Horse has a brilliant futurePainted Horse has a brilliant futurePainted Horse has a brilliant futurePainted Horse has a brilliant futurePainted Horse has a brilliant futurePainted Horse has a brilliant future
Most of the oils that are suitable for our trucks have a 400° or higher boil point.
So 240° is with in reason during hard work.

I assume your oil continued to heat up after you shut down, But I doubt it climbed more than 20-30° I think I read that you will see that message over 250° But I can't remember where, So take that with a grain of salt
But 242-244 is pretty common on hard pulls

  #7
Old 08-07-2018, 01:24 AM
kper05's Avatar
kper05
kper05 is offline
Post Fiend
Join Date: Jan 2010
Location: AL
Posts: 5,552
kper05 has a brilliant futurekper05 has a brilliant futurekper05 has a brilliant futurekper05 has a brilliant futurekper05 has a brilliant futurekper05 has a brilliant futurekper05 has a brilliant futurekper05 has a brilliant futurekper05 has a brilliant futurekper05 has a brilliant futurekper05 has a brilliant future
Originally Posted by Painted Horse View Post
Most of the oils that are suitable for our trucks have a 400° or higher boil point.
So 240° is with in reason during hard work.

I assume your oil continued to heat up after you shut down, But I doubt it climbed more than 20-30° I think I read that you will see that message over 250° But I can't remember where, So take that with a grain of salt
But 242-244 is pretty common on hard pulls
Your old post backs you up! I still cannot locate a document from Ford that discusses an acceptable range.

The truck de-rates somewhere in the 240's doesn't it? Or is that what happens at 250°F (which is getting too hot in my opinion)?

https://www.ford-trucks.com/forums/1...l#post11737463

Originally Posted by Painted Horse View Post
Last summer we asked about this and the response from the Ford Engineers was that 242 was still with in the design specs for this engine/oil. So unless you see something higher than that, You are fine.



  #8
Old 08-07-2018, 05:04 AM
senix's Avatar
senix
senix is offline
Moderator
Join Date: Aug 2008
Location: Frederick, MD
Posts: 29,118
senix has a superb reputationsenix has a superb reputationsenix has a superb reputationsenix has a superb reputationsenix has a superb reputationsenix has a superb reputationsenix has a superb reputationsenix has a superb reputationsenix has a superb reputationsenix has a superb reputationsenix has a superb reputation
I have hit as high as 248 with no derate in power. I do seem to recall 250 being the point at which it will limit power.

  #9
Old 08-07-2018, 08:09 AM
Pocket
Pocket is offline
Moderator
Join Date: Jun 2004
Location: Parker, CO
Posts: 8,944
Pocket has a superb reputationPocket has a superb reputationPocket has a superb reputationPocket has a superb reputationPocket has a superb reputationPocket has a superb reputationPocket has a superb reputationPocket has a superb reputationPocket has a superb reputationPocket has a superb reputationPocket has a superb reputation
Originally Posted by kper05 View Post
Your old post backs you up! I still cannot locate a document from Ford that discusses an acceptable range.

The truck de-rates somewhere in the 240's doesn't it? Or is that what happens at 250°F (which is getting too hot in my opinion)?
Oil temps on these trucks can easily hit the 240's range with no ill effects whatsoever. The oil is fine and the engine won't be harmed. These trucks are designed to run hot like that.

Same goes for the trans temp.

  #10
Old 08-07-2018, 08:11 AM
jav_eee
jav_eee is online now
Senior User
Join Date: May 2017
Posts: 391
jav_eee is gaining momentum as a positive member of FTE.jav_eee is gaining momentum as a positive member of FTE.
Originally Posted by The Bone
I also let mine cool down before shutting it off. I do a lot of traveling with my 5th wheel and never shut it off when fueling. It's funny how much thinking you have to do when owning a diesel. You have to wait till the glow plug light goes off before starting the engine. Then wait till it cools down to normal operating temp before shutting it off. I only use synthetic oil because it works better under extreme conditions better than the blend. The blend doesn't mean a 50/50 ether. Not sure how much synthetic oil that they can use to call it a blend. Doesn't say on the can.
You have to wait for the glow plug light to go off? Whoops!

  #11
Old 08-07-2018, 10:16 AM
HRTKD's Avatar
HRTKD
HRTKD is offline
Post Fiend
Join Date: Oct 2015
Location: Somewhere south of Denver
Posts: 5,523
HRTKD has a brilliant futureHRTKD has a brilliant futureHRTKD has a brilliant futureHRTKD has a brilliant futureHRTKD has a brilliant futureHRTKD has a brilliant futureHRTKD has a brilliant futureHRTKD has a brilliant futureHRTKD has a brilliant futureHRTKD has a brilliant futureHRTKD has a brilliant future
ajp207, was this going over Rabbit Ears Pass? I was there on Sunday going east. 30+ minute wait to get past it. Wait 2 minutes, move forward 200 yards, stop, wait 2 minutes, move forward 200 yards, etc, etc. The first stop I let the engine idle, the second stop I shut it down.

Like Senix said above, my engine oil temp often gets into the low 240's without any issues. A good synthetic oil won't have a problem going 30° F over that.

  #12
Old 08-07-2018, 01:00 PM
Tim C's Avatar
Tim C
Tim C is offline
Senior User
Join Date: Apr 2004
Location: Fayetteville, NC
Posts: 224
Tim C is gaining momentum as a positive member of FTE.
Originally Posted by kper05 View Post
Your old post backs you up! I still cannot locate a document from Ford that discusses an acceptable range.

The truck de-rates somewhere in the 240's doesn't it? Or is that what happens at 250°F (which is getting too hot in my opinion)?

https://www.ford-trucks.com/forums/1...l#post11737463





Not sure on the 6.7s but the 6.0s would derate or cut fuel, at 253 degrees. I felt it several times when towing with a questionable oil cooler on my old 6.0.


  #13
Old 08-07-2018, 02:16 PM
troverman's Avatar
troverman
troverman is offline
Post Fiend
Join Date: Apr 2013
Location: NH
Posts: 9,047
troverman has much to be proud oftroverman has much to be proud oftroverman has much to be proud oftroverman has much to be proud oftroverman has much to be proud oftroverman has much to be proud oftroverman has much to be proud oftroverman has much to be proud oftroverman has much to be proud of
Originally Posted by The Bone View Post
It's funny how much thinking you have to do when owning a diesel. You have to wait till the glow plug light goes off before starting the engine. Then wait till it cools down to normal operating temp before shutting it off. I only use synthetic oil because it works better under extreme conditions better than the blend. The blend doesn't mean a 50/50 ether. Not sure how much synthetic oil that they can use to call it a blend. Doesn't say on the can.
You really don't need to wait for the glow plug light. Only in the extreme cold (say +10F or below) would it really be a problem if you didn't. And while I agree that idling for a couple of minutes after a very hard pull is a good idea, you probably don't need to. Ford specifically tests their engines for survivability of shutting down after an extreme run. Turbo cooling through coolant convection is much improved over the early days. As for oil, Ford diesel oil isn't even a blend unless you specifically request it. It's just standard 10w30 diesel oil.


  #14
Old 08-08-2018, 08:28 AM
ajp207
ajp207 is offline
New User
Thread Starter
Join Date: Aug 2018
Posts: 3
ajp207 is starting off with a positive reputation.
Oil temp warning

Originally Posted by HRTKD View Post
ajp207, was this going over Rabbit Ears Pass? I was there on Sunday going east. 30+ minute wait to get past it. Wait 2 minutes, move forward 200 yards, stop, wait 2 minutes, move forward 200 yards, etc, etc. The first stop I let the engine idle, the second stop I shut it down.

Like Senix said above, my engine oil temp often gets into the low 240's without any issues. A good synthetic oil won't have a problem going 30° F over that.
I was going over million dollar highway Ouray to Durango, Thanks for all the help

  #15
Old 08-08-2018, 08:35 AM
ajp207
ajp207 is offline
New User
Thread Starter
Join Date: Aug 2018
Posts: 3
ajp207 is starting off with a positive reputation.
Oil temp warning

Originally Posted by senix View Post
Turbo's are the issue here. hot oil means no lube on the bearings.
So, this is new to me, at what temp do you think this would become and issue, Thanks in advance
