Radiator replacement/ coolant leak
Hotshot
Joined: Jul 2008
Posts: 12,782
Likes: 2,142
From: N.GA Mountains
If the cups are not leaking, but coolant is getting in the crankcase - a cavitation-induced hole in cylinder wall is a possibility.... Not many places this can happen and high pressure (exhaust gasses) could explain failed radiator. With oil drained and plug out, see if water gets into pan when pressure testing cooling system.
This engine stops in one of (4) places each time you shut it off. When your cylinder to cooling passage leak is on a cylinder that is ‘UP’ at shutdown, the water/coolant can go directly into crankcase. If that cylinder is ‘DOWN’ the water would go into the combustion chamber and be pushed out GP hole when rotating the engine to evacuate cylinders as you described.
Thread Starter
|
Laughing Gas
Joined: Feb 2014
Posts: 1,041
Likes: 72
From: Springfield
None of that sound good but I’ll fill it back up and see what happens. Was really hoping not to have to open up the engine again. So from what everyone thinks, would I be best to go ahead and pull the engine so I can test it on a stand and start tearing it down when I find the problem? Ive already got most of the engine bay disassembled for easy access.
Thread Starter
|
Laughing Gas
Joined: Feb 2014
Posts: 1,041
Likes: 72
From: Springfield
You don’t know how true that is, and from the last rebuild. It was 6 years to the day from when I bought the truck when I pulled it in to swap injectors and glow plugs. Had coolant coming out of the glow plug bore after injectors then the glow plugs were removed. So rebuilt it and no issues till now. Never had any cross contamination of anything. I’ll be pulling the engine tomorrow to see what’s going on and hopefully find my issue. I’d imagine I can pull the pan then do a coolant system pressure test to see if it’s coming from a cylinder
FTE Leadership Emeritus
Joined: May 2014
Posts: 27,352
Likes: 5,946
From: Lake Hartwell, GA
You don’t know how true that is, and from the last rebuild. It was 6 years to the day from when I bought the truck when I pulled it in to swap injectors and glow plugs. Had coolant coming out of the glow plug bore after injectors then the glow plugs were removed. So rebuilt it and no issues till now. Never had any cross contamination of anything. I’ll be pulling the engine tomorrow to see what’s going on and hopefully find my issue. I’d imagine I can pull the pan then do a coolant system pressure test to see if it’s coming from a cylinder
Be sure to post pictures of what you find!
Thread Starter
|
Laughing Gas
Joined: Feb 2014
Posts: 1,041
Likes: 72
From: Springfield
Should be able to get the engine out today. It won’t be as easy this time though, last time I was in a truck shop and was able to use the forklift to pull the engine. Hopefully will have a reasonable idea of what’s wrong by this evening. I’ll be sure to keep you all updated
FTE Stories
Ford Trucks for Ford Truck Enthusiasts
10 Things Every Truck Owner NEEDS (2026 Edition)
Michael S. Palmer
Rezvani's Latest Post-Apocalyptic Monster Is a Ford F-150 Raptor Underneath
Verdad Gallardo
Top 10 Most Expensive Ford Trucks Ever Sold on Bring a Trailer
Joe Kucinski
2027 Ford Super Duty Buyer's Guide (Every Model, Engine, & Package)
Brett Foote
Top 10 Ford Truck Tragedies
Joe Kucinski
AEV FXL Super Duty - the Super Duty Raptor Ford Doesn't Make
Brett Foote
Lobo Vs Lobo: Proof the F-150 Lobo Should Be Even Lower!
Michael S. Palmer
Ford's 2001 Explorer Sportsman Concept Looks For a New Home
Verdad Gallardo
10 Best Ford Truck Engines We Miss the Most!
Joe Kucinski
Hotshot
Joined: Jul 2008
Posts: 12,782
Likes: 2,142
From: N.GA Mountains
Should be able to get the engine out today. It won’t be as easy this time though, last time I was in a truck shop and was able to use the forklift to pull the engine. Hopefully will have a reasonable idea of what’s wrong by this evening. I’ll be sure to keep you all updated
https://m.youtube.com/watch?v=lX5yQDqChx0
Thread Starter
|
Laughing Gas
Joined: Feb 2014
Posts: 1,041
Likes: 72
From: Springfield
I left the ac all together and the power steering hooked up last time and this time when I pulled the engine. But I did pull the header panel both times. Engine crane wasn’t bad this time but I wish my driveway was a little smoother.
Since I said I’d keep you all updated, I started a new post, I found a cracked cylinder. When I dropped the pan I saw chunks. Fished them out and they’re pieces of a piston and the oiler nozzle for the piston. So now it’s time for me to figure out what I’m gonna do.
Since I said I’d keep you all updated, I started a new post, I found a cracked cylinder. When I dropped the pan I saw chunks. Fished them out and they’re pieces of a piston and the oiler nozzle for the piston. So now it’s time for me to figure out what I’m gonna do.
