Jul 8, 2019 | 10:51 AM

#31

CamoF-250

Elder User

Joined: Oct 2009

Posts: 534

Likes: 3

From: Chesapeake

No I did not. I want to say google lead me to believe out computers check for functionality at a different point in the start up sequence. I can try it again later I guess. Used EGR from a pick n pull ran me like 8 dollars and solved it for me.

Jul 11, 2019 | 04:58 PM

#32

torq'ta 5 8

Lead Driver

Joined: Jan 2019

Posts: 5,075

Likes: 865

From: N.W. Alabama

buddy's 94 5.0l truck didnt work for him, but when he put on his mustang it worked, I've asked him which one he got, he cant remember except it said mustang/f150 EGR delete plug

Jul 17, 2019 | 10:05 PM

#33

dusty78

Senior User

Joined: Jun 2019

Posts: 109

Likes: 0

From: nw arkansas

I did the smog and egr delets on my 93 ford bronco and my 94 f250 both work well no codes or check engine lights the bronco with the 302 I used the method described by sandwich a price of tin between and left rest in tact my f250 with the 351w I used a block off plate and the little plug thing I removed all canesters except the vacuum one for obvious reasons I and Unnecessary vacuum lines I think I left 3 or 4 the switches by coil I left electrical plugs in but no vacuum lines connected the cats are removed but still have o2 sensor

Jul 17, 2019 | 10:12 PM

#34

dusty78

Senior User

Joined: Jun 2019

Posts: 109

Likes: 0

From: nw arkansas

I bought censer thing and egr block on eBay

Jul 22, 2019 | 11:02 AM

#35

CamoF-250

Elder User

Joined: Oct 2009

Posts: 534

Likes: 3

From: Chesapeake

I think there is a link on here on how to build the censor thing for our trucks. Your ebay one must be correct for a F-series ECM or I might have a dud 5.0 one. It did not work for my 5.8 and solid gasket with a salvaged EGR has disabled mine without codes.

Correction: With out check engine lights, I do get a code for thermactor air inoporative.

Jul 22, 2019 | 11:25 AM

#36

jackietreehorn

Cargo Master

Joined: Oct 2016

Posts: 2,738

Likes: 217

From: Northern VA

I think the bypass thing does the same thing as a couple 10 cent resistors. Maybe the value needed to fool the computer is different on truck than stang.

Aug 1, 2019 | 10:10 AM

#37

nekkidhillbilly

Mountain Pass

Joined: Aug 2019

Posts: 151

Likes: 1

Quote:

Originally Posted by jackietreehorn

I think the bypass thing does the same thing as a couple 10 cent resistors. Maybe the value needed to fool the computer is different on truck than stang.

pretty sure its 75 ohm for the trucks
