hpop---???
Lead Driver
Joined: Apr 2016
Posts: 7,213
Likes: 1,342
From: Bahstun
Thanks for correction, I was thinking of another pump design
Hotshot
Joined: Dec 2005
Posts: 14,377
Likes: 609
From: evansville in
Have you cranked engine with valve covers off to make sure no orings were cut?
What was the duty cycle doing while cranking at that 140 psi. It should have been from my experience 50% and rising or there about.
We had your same issue on my brothers truck a while back and at 300k a new IPR and t500 and it runs better than it had in 100k. More pep in its step for sure.
Hotshot
Joined: Dec 2005
Posts: 14,377
Likes: 609
From: evansville in
IPR is measured in duty cycle% .on vs off . letting oil back to tank to control pressure vs flow rate.
ICP is pressure.
Pressure is regulated via IPR based on ICP feedback psi.
ICP is pressure.
Pressure is regulated via IPR based on ICP feedback psi.
FTE Stories
Ford Trucks for Ford Truck Enthusiasts
Top 10 Fords at 2026 Carlisle Ford Nationals
Joe Kucinski
3 Best / 3 Worst Parts of Modern Ford Ownership
Brett Foote
10 Amazing Upgrades That Solve Common Ford Truck Owner Headaches
Pouria Savadkouei
Every 2026 Ford Engine Explained
Brett Foote
10 Ugly Ford Trucks That We Still Kinda Love
Joe Kucinski
10 Things Every Truck Owner NEEDS (2026 Edition)
Michael S. Palmer
Rezvani's Latest Post-Apocalyptic Monster Is a Ford F-150 Raptor Underneath
Verdad Gallardo
Top 10 Most Expensive Ford Trucks Ever Sold on Bring a Trailer
Joe Kucinski
2027 Ford Super Duty Buyer's Guide (Every Model, Engine, & Package)
Brett Foote
Lead Driver
Joined: Apr 2016
Posts: 7,213
Likes: 1,342
From: Bahstun
You need a scanner and start to trouble shoot before tossing big coin at unknowns. Unless you are rich and don't care.
Because racetruck
Joined: Apr 2007
Posts: 2,786
Likes: 104
From: Monterey Bay, CA
I would check it before replacing but to answer your question, no they aren't the same. Riffraffs is a 17º and XDP is a 15º.
