Glow plug relay bad already?
Thread Starter
|
Logistics Pro
Joined: Jan 2021
Posts: 4,077
Likes: 1,143
From: Fairhope Alabama
Glow plug relay bad already?
It got cold AF last night. This morning my truck wouldn't crank. It just turned over and turned over with a cloud of white smoke that would scare the neighborhood, and it never cranked. I also noticed that my battery meter never went down when I turned the key over. So, I got under the hood and bridged the two big poles on the glow plug relay for about 20 seconds, and she fired right up. What I didn't understand is, when I crossed the two poles, I didn't see any Sparks. I would have thought it would have been like a starter relay whereas when you crossed it it would spark as the screwdriver came into contact. It never did that. But she fired right up immediately with no hesitation after that. The glow plug relay was replaced by the previous owner 2 years ago with a part from the auto parts store. I know they are junk and I am probably lucky to have gotten two years from it. My question is, what's the best one to go with? Do the auto parts stores carry a specific brand that I can have in a couple of days that's worth a toot? Or do I have to order it and wait a week and keep crossing the relay?
Tuned
Joined: Jun 2007
Posts: 431
Likes: 66
Stancor/ White-Rodgers:
#16-009 White-Rodgers (Stancor) 586 902 Monster Glow Plug Relay.
Make sure you look at the amp rating capacity - startup and continuous.
This is beefy and I think guys have used one or two others which are good.
Do install the LED GP light - no brained.
#16-009 White-Rodgers (Stancor) 586 902 Monster Glow Plug Relay.
Make sure you look at the amp rating capacity - startup and continuous.
This is beefy and I think guys have used one or two others which are good.
Do install the LED GP light - no brained.
Thread Starter
|
Logistics Pro
Joined: Jan 2021
Posts: 4,077
Likes: 1,143
From: Fairhope Alabama
That looks quite a bit different from the oem. I can tell from the look of it it doesn't look like it's made for this application but, since you posted it, I assume that means it's pretty good and an upgrade over what else we can find. It looks like the mounts might not line up but, I guess that is a minor inconvenience if it means upgrading to a better relay. Thank you, I will look into it!
Thread Starter
|
Logistics Pro
Joined: Jan 2021
Posts: 4,077
Likes: 1,143
From: Fairhope Alabama
It didn't get into the negatives but it sure got cold enough. It wasn't too bad. I would definitely have to get a custom to that weather for a while before I could live there comfortably. Heck I don't know if there ever is a way to live there comfortably. Probably sucks for you even though you've been there for so long. That's just too darn cold!
Thread Starter
|
Logistics Pro
Joined: Jan 2021
Posts: 4,077
Likes: 1,143
From: Fairhope Alabama
Stancor/ White-Rodgers:
#16-009 White-Rodgers (Stancor) 586 902 Monster Glow Plug Relay.
Make sure you look at the amp rating capacity - startup and continuous.
This is beefy and I think guys have used one or two others which are good.
Do install the LED GP light - no brained.
#16-009 White-Rodgers (Stancor) 586 902 Monster Glow Plug Relay.
Make sure you look at the amp rating capacity - startup and continuous.
This is beefy and I think guys have used one or two others which are good.
Do install the LED GP light - no brained.
Trending Topics
Lead Driver
Joined: Jul 2017
Posts: 6,855
Likes: 2,332
From: WV
My part store relay only lasted a couple years. Unfortunately I didn’t realize I’d already replaced it until I put the new part relay on.
Next time I will just cross the relay and wait until a good one can ship in. I see a lot of guys using the trombetta (spelling?) lately. Supposedly it fits more like stock than some of the other “upgrades”.
I was planning on doing a LED for the GPR because inevitability the non working condition sneaks up on me with my limited use of the truck. I even ordered in some LEDs for the mod. But since then I’ve decided I may rather find a digital voltmeter for the power port and use it. Less fuss and who couldn’t use an extra USB charge port?
Next time I will just cross the relay and wait until a good one can ship in. I see a lot of guys using the trombetta (spelling?) lately. Supposedly it fits more like stock than some of the other “upgrades”.
I was planning on doing a LED for the GPR because inevitability the non working condition sneaks up on me with my limited use of the truck. I even ordered in some LEDs for the mod. But since then I’ve decided I may rather find a digital voltmeter for the power port and use it. Less fuss and who couldn’t use an extra USB charge port?
FTE Stories
Ford Trucks for Ford Truck Enthusiasts
Rezvani's Latest Post-Apocalytic Monster Is a Ford F-150 Raptor Underneath
Verdad Gallardo
Top 10 Most Expensive Ford Trucks Ever Sold on Bring a Trailer
Joe Kucinski
2027 Ford Super Duty Buyer's Guide (Every Model, Engine, & Package)
Brett Foote
Top 10 Ford Truck Tragedies
Joe Kucinski
AEV FXL Super Duty - the Super Duty Raptor Ford Doesn't Make
Brett Foote
Lobo Vs Lobo: Proof the F-150 Lobo Should Be Even Lower!
Michael S. Palmer
Ford's 2001 Explorer Sportsman Concept Looks For a New Home
Verdad Gallardo
10 Best Ford Truck Engines We Miss the Most!
Joe Kucinski
2026 Shelby F-150 Off-Road: Better Than a Raptor R?
Brett Foote
Thread Starter
|
Logistics Pro
Joined: Jan 2021
Posts: 4,077
Likes: 1,143
From: Fairhope Alabama
My part store relay only lasted a couple years. Unfortunately I didn’t realize I’d already replaced it until I put the new part relay on.
Next time I will just cross the relay and wait until a good one can ship in. I see a lot of guys using the trombetta (spelling?) lately. Supposedly it fits more like stock than some of the other “upgrades”.
I was planning on doing a LED for the GPR because inevitability the non working condition sneaks up on me with my limited use of the truck. I even ordered in some LEDs for the mod. But since then I’ve decided I may rather find a digital voltmeter for the power port and use it. Less fuss and who couldn’t use an extra USB charge port?
Next time I will just cross the relay and wait until a good one can ship in. I see a lot of guys using the trombetta (spelling?) lately. Supposedly it fits more like stock than some of the other “upgrades”.
I was planning on doing a LED for the GPR because inevitability the non working condition sneaks up on me with my limited use of the truck. I even ordered in some LEDs for the mod. But since then I’ve decided I may rather find a digital voltmeter for the power port and use it. Less fuss and who couldn’t use an extra USB charge port?
Lead Driver
Joined: Jul 2017
Posts: 6,855
Likes: 2,332
From: WV
Which voltmeter did you go with?
I know it can be seen on the dash gauge as well but why not buy a cheap new “toy”?
I do need to learn to keep an eye on the gauge after startup. The main idea is to quickly spot a bad GPR instead of waiting until it’s cold and catches me off guard. That’s what happened last time. It was starting a little more “sluggish” for a while, then had a cold day and didn’t want to start at all. Finally dawned on me at that point.
Hotshot
Joined: Mar 2014
Posts: 10,750
Likes: 1,065
From: Douglassville, PA
A relay is a relay is a relay. It is an electromagnetic switch that uses low amps to control a switch that handles high amps. I cannot find the one I installed about 7 years ago but I got it off of fleabay and it looked similar to this. You just want to make sure that it's rated for the amps involved (I don't know what that is) and you might have to wing it with the mounting holes.
https://www.ebay.com/itm/27344805131...3ABFBM_NCT-O9f
https://www.ebay.com/itm/27344805131...3ABFBM_NCT-O9f
It's a Van Gogh
Joined: Feb 2010
Posts: 7,812
Likes: 1,335
From: Elk Grove, CA
That looks quite a bit different from the oem. I can tell from the look of it it doesn't look like it's made for this application but, since you posted it, I assume that means it's pretty good and an upgrade over what else we can find. It looks like the mounts might not line up but, I guess that is a minor inconvenience if it means upgrading to a better relay. Thank you, I will look into it!
FTE Leadership Emeritus
Joined: May 2014
Posts: 27,352
Likes: 5,946
From: Lake Hartwell, GA
As mentioned above, Trombetta all the way...
Quality part that is a direct factory replacement. The WR/Stancor is a nice part, but it is twice the size and requires a bit of finagling to get it mounted properly.
Link:
More info...
Link: https://www.ford-trucks.com/forums/1...?highlight=Gpr
Quality part that is a direct factory replacement. The WR/Stancor is a nice part, but it is twice the size and requires a bit of finagling to get it mounted properly.
Link:
More info...
Link: https://www.ford-trucks.com/forums/1...?highlight=Gpr
Thread Starter
|
Logistics Pro
Joined: Jan 2021
Posts: 4,077
Likes: 1,143
From: Fairhope Alabama
Found a link in the tech folder. https://www.ford-trucks.com/forums/1...l#post19172939
Which voltmeter did you go with?
I know it can be seen on the dash gauge as well but why not buy a cheap new “toy”?
I do need to learn to keep an eye on the gauge after startup. The main idea is to quickly spot a bad GPR instead of waiting until it’s cold and catches me off guard. That’s what happened last time. It was starting a little more “sluggish” for a while, then had a cold day and didn’t want to start at all. Finally dawned on me at that point.
Which voltmeter did you go with?
I know it can be seen on the dash gauge as well but why not buy a cheap new “toy”?
I do need to learn to keep an eye on the gauge after startup. The main idea is to quickly spot a bad GPR instead of waiting until it’s cold and catches me off guard. That’s what happened last time. It was starting a little more “sluggish” for a while, then had a cold day and didn’t want to start at all. Finally dawned on me at that point.
I don't currently have a voltmeter charger. iirc, the last car charger I had messed up for some reason or wouldn't work on my truck anymore. I don't remember. I need to pick one up. I will prob pick one up at Wally world just fun. I will try to find a better one on Amazon at a later date but for now, I will see how Wally world does. Edit* Wally world didn't have one. Here's the one I want. I might look for one with two USB ports instead of one, at the same time I wanted to try out one of those C to C chargers
[Pure Copper] USB C Car Charger, SUPERONE 38W Dual USB Car Charger Adapter with 20W PD Port, Fast QC3.0 and LED Voltmeter for iPhone 13 Pro Max/Pro/Mini, Google Pixel 6/5/4, Samsung S21/20 and More https://www.amazon.com/dp/B085LKLCYX/ref=cm_sw_r_awdo_Z9GJC9XP7ZSY8EGW4DAZ
The truck cranked up fine yesterday, except for the long start which I blamed on air in the h-pop system. Maybe it was due to the glow plugs not turning on. Luckily, I quickly figured out it was the GP relay. I have a new one on its way. Thank you for the link and your help!
