Glove box

Thread Tools

Search this Thread

Old Jun 28, 2019 | 11:37 PM
  #1
ranger140892's Avatar
ranger140892
Thread Starter
|
Grumpy goat
Veteran: Army
5 Year Member
Photogenic
Photoriffic
Joined: May 2017
Posts: 3,059
Likes: 597
Club FTE Gold Member
Glove box

Here's a bonehead question: What's the procedure for installing a glove box? I've been without one for too long. I ordered a plastic box from JBG a couple of years ago, but they never got them in stock. I'll settle for the factory type. Please tell me I don't have to remove the dash board or front panel. Thanks, Guys.

Reply
Old Jun 29, 2019 | 06:57 AM
  #2
73GreenBean's Avatar
73GreenBean
Senior User
5 Year Member
Joined: Jan 2019
Posts: 334
Likes: 3
From: Indiana
If I remember right I slid my cardboard type up under the dash but I can't remember if I had my heater and fan assembly still under there at the time. I know it takes some patience and it's goes in at a weird angle but if you're careful you should be able to bend and pry a little at a time without ripping the cardboard. Good luck

Reply
Old Jun 29, 2019 | 09:04 AM
  #3
77&79F250's Avatar
77&79F250
Moderator & parts slinger
Veteran: Army
15 Year Member
Community Builder
Liked
Joined: Feb 2007
Posts: 50,272
Likes: 5,824
From: S/W Missouri, Polk county
Club FTE Gold Member
A/C truck? Is sort of a PITA with less room, none a/c... a little less a PITA. lol Yes just carefully slide/slip/push/maneuver it up from under and behind the dash. Careful, because the pressed glove box dash hole on the dash can have some sharp edges. Especially the L and R short edge ones. Do you have a L/H side glove box light? Get it out of the way before hand. They come out easier than they go in.



Reply
Old Jun 29, 2019 | 10:23 AM
  #4
NiagaraFord's Avatar
NiagaraFord
New User
Joined: Jun 2019
Posts: 8
Likes: 0
Take your time, I’ve destroyed three glove boxes trying to install them 🤷🏻*♂️

Reply
Old Jun 29, 2019 | 11:11 AM
  #5
ranger140892's Avatar
ranger140892
Thread Starter
|
Grumpy goat
Veteran: Army
5 Year Member
Photogenic
Photoriffic
Joined: May 2017
Posts: 3,059
Likes: 597
Club FTE Gold Member
Thank you very much, Gentlemen.

Mine is non A/C, so should be a little easier. I wish I had done this when I changed the heater core.

Reply
Old Jun 29, 2019 | 11:31 PM
  #6
Redrokin09's Avatar
Redrokin09
Senior User
5 Year Member
Photogenic
Photoriffic
Shutterbug
Joined: May 2019
Posts: 338
Likes: 3
From: UT - Utah
Mine has A/C and they're easy to get in and out. Make sure you remove the limit strap cable, remove the uper latch. Go in at an angle with your right hand in first and then feed it through. It super easy.

Reply
Old Jun 30, 2019 | 10:02 AM
  #7
ranger140892's Avatar
ranger140892
Thread Starter
|
Grumpy goat
Veteran: Army
5 Year Member
Photogenic
Photoriffic
Joined: May 2017
Posts: 3,059
Likes: 597
Club FTE Gold Member
Thanks, Redrokin09.

Reply
Old Jun 30, 2019 | 09:46 PM
  #8
John89's Avatar
John89
Fleet Mechanic
5 Year Member
Photogenic
Photoriffic
Shutterbug
Joined: Jul 2017
Posts: 1,448
Likes: 163
From: East Texas
Did ours today.

Took door completely off.
Removed top latch.
Fed it through the front, then worked it into place once it went through. I wasn't going to try to go in from the back, it just didn't seem like it would go.

Had to give it some gentle nudges to get it to go through the opening.

10 minute job.

Ours is non AC.

Reply
FTE Stories

Ford Trucks for Ford Truck Enthusiasts

story-0

10 Ways Ford is LOSING to the Competition

 Joe Kucinski
story-1

Top 6 Best Deals Available on New Fords & Lincolns Right Now

 Brett Foote
story-2

This Hennessey Takes the Expedition Tremor's Off-Roading Capability to the Next Level

 Verdad Gallardo
story-3

Top 10 Fords at 2026 Carlisle Ford Nationals

 Joe Kucinski
story-4

3 Best / 3 Worst Parts of Modern Ford Ownership

 Brett Foote
story-5

10 Amazing Upgrades That Solve Common Ford Truck Owner Headaches

 Pouria Savadkouei
story-6

Every 2026 Ford Engine Explained

 Brett Foote
story-7

10 Ugly Ford Trucks That We Still Kinda Love

 Joe Kucinski
story-8

10 Things Every Truck Owner NEEDS (2026 Edition)

 Michael S. Palmer
story-9

Rezvani's Latest Post-Apocalyptic Monster Is a Ford F-150 Raptor Underneath

 Verdad Gallardo
Old Jun 30, 2019 | 09:50 PM
  #9
ranger140892's Avatar
ranger140892
Thread Starter
|
Grumpy goat
Veteran: Army
5 Year Member
Photogenic
Photoriffic
Joined: May 2017
Posts: 3,059
Likes: 597
Club FTE Gold Member
Thanks, John. I'll order one from LMC or some place tonight before bed. Thanks to all you guys.

Reply
Old Jun 30, 2019 | 11:06 PM
  #10
maddogjohnson's Avatar
maddogjohnson
Laughing Gas
10 Year Member
Photogenic
Photoriffic
Shutterbug
Joined: Jan 2012
Posts: 888
Likes: 70
From: Santa Clarita
I just installed my glovebox a few days ago. I did it from underneath on my A/C truck. It wasn't too hard to do. I did have to pull out the A/C duct to get the glovebox up in there. My A/C duct needed to be cleaned out before reassembly so that was part of the reason I did it that way. It was just a matter of getting the right angle in moving the glovebox around once I got it up in the right area and then getting the right angles on the A/C duct to get it to all fit where it should. I did have one under dash electrical connection I had to unhook and move out of the way while installing the glovebox. I'm not sure what it's for.

w/o A/C I'm sure it's easier.

Reply
Old Jul 3, 2019 | 04:25 PM
  #11
ranger140892's Avatar
ranger140892
Thread Starter
|
Grumpy goat
Veteran: Army
5 Year Member
Photogenic
Photoriffic
Joined: May 2017
Posts: 3,059
Likes: 597
Club FTE Gold Member
I just installed my cardboard glove box. Just for s&g's, I slid it in from the front and from the rear to see which is easier. It was easier from the front. Thanks, Guys!

Reply
Old Jul 3, 2019 | 09:21 PM
  #12
hail destroyer's Avatar
hail destroyer
Elder User
Joined: Apr 2016
Posts: 854
Likes: 7


Whats the problem? mine practically fell out. 😁

Reply
Old Jul 3, 2019 | 09:50 PM
  #13
ranger140892's Avatar
ranger140892
Thread Starter
|
Grumpy goat
Veteran: Army
5 Year Member
Photogenic
Photoriffic
Joined: May 2017
Posts: 3,059
Likes: 597
Club FTE Gold Member
Dammit! All those other guys gave me erroneous info. Your way would make it much easier to get that top left screw to thread up. Next time I'll PM you.
