Wiring Schematics
My 1995 did not come with cruise control. I have retrofit the cruise control system, and as my brake master cylinder needed to be replaced I opted for the version with the threaded connection for the cruise-interrupt switch. All that is done, but I have not found any diagram that indicated where to wire the switch in to. I went to a salvage yard to look at other trucks with cruise. The two wires quickly disappear into a huge wire bundle, so getting any further that way is not impossible, but I will probably have to cut way back into that wiring bundle to figure out where these two wires go. Can anyone out there just tell me where they go?
Hotshot
Joined: Jun 2015
Posts: 12,763
Likes: 2,419
Sometimes the factory uses the same harness to streamline the assembly process and cut costs. I assume you looked all over that area and could not find a connector either loose or tucked into the harness? I’m asking because I have seen other speed control threads where the OP sourced all the parts from a donor truck and it all plugged into their truck.
Thread Starter
|
5th Wheeling
Joined: Oct 2017
Posts: 42
Likes: 6
Correct. I did do that. As you probably know, there is so much "stuff" mounted above that wiring harness that to really see what is going on there will take a bit of time to remove enough of it to see it well. But, I have seen where the connection disappears into the wiring harness on other trucks and that connection does not exist on my truck, nor does any similar unused connection.
Lead Driver
Joined: Jun 2021
Posts: 5,207
Likes: 798
Correct. I did do that. As you probably know, there is so much "stuff" mounted above that wiring harness that to really see what is going on there will take a bit of time to remove enough of it to see it well. But, I have seen where the connection disappears into the wiring harness on other trucks and that connection does not exist on my truck, nor does any similar unused connection.
