Wiper Motor availability

!978 F150 4x4 300 IL6
Wiper Motor
Does anyone know who is making or reworking these motors? I have one but it is making lots of noise. I am sure it is the motor because I removed it and tried it stand alone. It is vibrating from the gearbox.Do they sell the gearbox parts?
Thanks
Randy

Jan 10, 2022 | 11:13 PM

77&79F250

Moderator & parts slinger

Joined: Feb 2007

Posts: 50,251

Likes: 5,815

From: S/W Missouri, Polk county

Google shows a bunch of options. https://shop.advanceautoparts.com/fi...er-motor.c8282

C7TZ-17508-D .. Wiper Motor = 1967/79 F100/350 & 1978/79 Bronco. It's the same wiper motor used with or without intermittent wipers, which were introduced in 1973.

Jan 11, 2022 | 01:50 AM

hentzrd

Thread Starter

Mountain Pass

Joined: Jan 2012

Posts: 168

Likes: 7

From: TOWER CITY

I see there are some. But when I looked earlier I did not use the part number and it said what they had would not fit my truck. However there are none within 100 miles of me.and it says call to order. I will try tomorrow. If I get the intermittent
switch and the box for it will this motor work? I tried LMC, and Bronco Graveyard and they do not offer it.

Jan 11, 2022 | 08:07 AM

77&79F250

Moderator & parts slinger

Joined: Feb 2007

Posts: 50,251

Likes: 5,815

From: S/W Missouri, Polk county

You can get the delay wiper control module in a JY or new repop here. https://www.macsautoparts.com/1973-1...MaAuoVEALw_wcB

Switch here. https://shop.broncograveyard.com/197...oaAnnWEALw_wcB

Old info but good info.Two differenttypes of windshield wipers, two differentwiper switches. Two speed wiper switches have a low & high speed.
Intermittent (delay) wipers were optional on 1973/79 F100/350's and 1978/79 Bronco's. Intermittent is not another name for low speed!
DOOZ-17A553-A.. Two Speed Wiper Switch-Notused with intermittent wipers (Motorcraft SW-896) / Marked: D0OB-17A553-A orD/ Obsolete
1973/79 F100/350 / 1978/79 Bronco // 1970/71 Fairlane/Torino/Montego / 1970/72 Maverick/Comet.
SUSANVILLE FORD in Susanville CA = 530-257-2137.
NOS ONLY in San Jose CA = 800-667-6659.
WESLEY OBSOLETE PARTS in Liberty KY= 606-787-5293.
GREEN SALES CO. in Cincinnati OH = 800-543-4959.
D1OZ-17A553-A.. Two Speed Wiper Switch-Used withintermittent wipers (Motorcraft SW-1010) / Marked: D1OB-17A553-AA/ Obsolete
1973/79 F100/350 / 1978/79 Bronco // 1971 Fairlane/Torino/Montego.
NOS ONLY
BURNS FORD in Burns OR = 541-573-7278.
WESLEY OBSOLETE PARTS
GREEN SALES CO.

And D1OZ-17A553-A.. Two Speed Wiper Switch-Used with intermittent wipers (Motorcraft SW-1010) / Marked: D1OB-17A553-AA / Obsolete
DON'S TRUCK SALES in Fairbank IA= 319-365-2751.
MCDONALD OBSOLETE PARTS CO. in Rockport IN= 812-359-4965.
WESLEY OBSOLETE PARTS in Liberty KY= 606-787-5293.
GREEN SALES CO. in Cincinnati OH= 800-543-4959.
CARPENTER NOS OBSOLETE PARTS in Concord NC = 800-476-9653.
There are TWO different intermittent wiper governors. 1973/77 is one type, 1978/79 is another.
D3TZ-17C476-A(replaced D1ZZ-17C476-A) Intermittent Wiper Governor / Obsolete

Jan 11, 2022 | 08:40 AM

hentzrd

Thread Starter

Mountain Pass

Joined: Jan 2012

Posts: 168

Likes: 7

From: TOWER CITY

I purchased them from LMC but I was not sure if the motor was different. I don't think it is. I should be good. But thanks for all the information. You can never have enough when yu are doing a frame up rebuild.
Thanks
Randy

Jan 11, 2022 | 08:42 AM

77&79F250

Moderator & parts slinger

Joined: Feb 2007

Posts: 50,251

Likes: 5,815

From: S/W Missouri, Polk county

Well if it is information you like, have you been here? https://www.ford-trucks.com/forums/1...then-some.html

Or here? https://www.ford-trucks.com/forums/1...l#post20013315

And even here? https://www.ford-trucks.com/forums/1...l#post20013316

Jan 11, 2022 | 08:56 AM

hentzrd

Thread Starter

Mountain Pass

Joined: Jan 2012

Posts: 168

Likes: 7

From: TOWER CITY

I have been to some of them not sure I saw them all Thanks

This Hennessey Takes the Expedition Tremor's Off-Roading Capability to the Next Level

Verdad Gallardo

Top 10 Fords at 2026 Carlisle Ford Nationals

Joe Kucinski

3 Best / 3 Worst Parts of Modern Ford Ownership

Brett Foote

10 Amazing Upgrades That Solve Common Ford Truck Owner Headaches

Pouria Savadkouei

Every 2026 Ford Engine Explained

Brett Foote

10 Ugly Ford Trucks That We Still Kinda Love

Joe Kucinski

10 Things Every Truck Owner NEEDS (2026 Edition)

Michael S. Palmer

Rezvani's Latest Post-Apocalyptic Monster Is a Ford F-150 Raptor Underneath

Verdad Gallardo

Top 10 Most Expensive Ford Trucks Ever Sold on Bring a Trailer

Joe Kucinski

2027 Ford Super Duty Buyer's Guide (Every Model, Engine, & Package)

Brett Foote

Jan 11, 2022 | 10:02 AM

mikeo0o0o0

Hotshot

Joined: Apr 2009

Posts: 14,333

Likes: 247

From: Stanley, VA

Quote:

Originally Posted by hentzrd

!978 F150 4x4 300 IL6
Wiper Motor
Do they sell the gearbox parts?

To answer your question, Ford did sell individual parts for the wiper motor including gearbox parts. There's an exploded diagram of the motor assembly in the parts catalog. Whether any are still available is another mater.
