Solid door glass 1953-1955
Happy Memorial Day Weekend! I want to install solid door glass (one piece windows) in my 54 F100. I am sure a bunch of you have done! Can you share which companies windows a kit you used? I appreciate your help guys.
Fleet Mechanic
Joined: Apr 2015
Posts: 1,585
Likes: 483
From: Kemptville, ON,
I used the curved glass. The straight glass involves cutting up your doors both inside and out to make work.
Mountain Pass
Joined: Apr 2021
Posts: 215
Likes: 29
From: Hazel Green, Alabama
Here is a link to the tinted glass at mid fifty.
Tinted curved glass
I wonder if it is tinted green, kind of like the old green coke bottles. Anything real dark wouldn't work for me. Night cruising is a problem for me if the glass is too dark.
Tinted curved glass
I wonder if it is tinted green, kind of like the old green coke bottles. Anything real dark wouldn't work for me. Night cruising is a problem for me if the glass is too dark.
Fleet Mechanic
Joined: Dec 2005
Posts: 1,603
Likes: 44
Trending Topics
Lead Driver
Joined: Aug 2006
Posts: 8,093
Likes: 653
From: Brentwood, TN
I have done both the curved and the flat 1-piece side window installs using the MidFifty kits. The first question I would ask is, "who is doing the install"? If you are doing it yourself then you should be able to weld sheetmetal...more so with the flat glass but still some welding on the inner door with both applications. When the side window goes from stock to 1-piece the glass extends into the hinge pocket inside the door, this pocket needs to be cut so that the front window guide can be fixed in place. Access panels are cut out of the inner door to facilitate this mod and must be welded back in place. The flat glass install entails making the window slot in the top of the door straight by welding in new pieces that hold the felt wipers. It is not readily noticeable on an assembled door but the vent wing is on an angle from the side window...curved glass compensates for this bend whereas the flat glass kit eliminates the bend. The flat glass install entails more welding but in my opinion it is a much cleaner look...more like the 56 side windows.
FTE Stories
Ford Trucks for Ford Truck Enthusiasts
10 Things Every Truck Owner NEEDS (2026 Edition)
Michael S. Palmer
Rezvani's Latest Post-Apocalyptic Monster Is a Ford F-150 Raptor Underneath
Verdad Gallardo
Top 10 Most Expensive Ford Trucks Ever Sold on Bring a Trailer
Joe Kucinski
2027 Ford Super Duty Buyer's Guide (Every Model, Engine, & Package)
Brett Foote
Top 10 Ford Truck Tragedies
Joe Kucinski
AEV FXL Super Duty - the Super Duty Raptor Ford Doesn't Make
Brett Foote
Lobo Vs Lobo: Proof the F-150 Lobo Should Be Even Lower!
Michael S. Palmer
Ford's 2001 Explorer Sportsman Concept Looks For a New Home
Verdad Gallardo
10 Best Ford Truck Engines We Miss the Most!
Joe Kucinski
Fleet Mechanic
Joined: Apr 2015
Posts: 1,585
Likes: 483
From: Kemptville, ON,
I had never done it before, actually never built a hot rod before. That is random crap knowledge that will come into play. I had a hard time reading the instructions and translating it to the doing part. But slow and steady and I got it. The second side was much easier. I did the drivers side first and it works perfect, although I will probably lubricate the channels a bit as the window is a bit hard to go up. The passenger side I am having some trouble with now. Not sure why yet but it keeps jumping out f the track about 1/2 way up, I go down an inch and then up and it is fine. I will figure it out. I like the look of the one piece and that is why I went with it. You do have to do some cutting of the inside of the door but not a big deal, depending on what your finish door will look like, You do put the parts you cut out back in, the instructions say to screw them in. I will do that and cover the door with some sort of panel until I paint the truck and buy the interior finishes. For glass I went with clear, the green is like an old coke bottle colour and I did not want that look. If I need it tinted I will have that done locally.
FTE Legend
Joined: Oct 2005
Posts: 283,684
Likes: 8,271
From: northwestern Ontario
Here is a link to the tinted glass at mid fifty.
Tinted curved glass
I wonder if it is tinted green, kind of like the old green coke bottles. Anything real dark wouldn't work for me. Night cruising is a problem for me if the glass is too dark.
Tinted curved glass
I wonder if it is tinted green, kind of like the old green coke bottles. Anything real dark wouldn't work for me. Night cruising is a problem for me if the glass is too dark.
1st Gear
Joined: Jan 2024
Posts: 1
Likes: 0
Do you reuse the factory slide on the door striker side?
Lead Driver
Joined: Aug 2006
Posts: 8,093
Likes: 653
From: Brentwood, TN
Sounds like you've got the whole kit. Rear channel is reused and the front channel is in the kit.
Here is the instruction file: INST-CURVED_SOLID_SIDE-R.pdf (midfifty.com)
Here is the instruction file: INST-CURVED_SOLID_SIDE-R.pdf (midfifty.com)
