If the high pressure oil psi is changing depending on the ICP being plugged in, that suggests the IPR is working. Should fluctuate more than 100 psi of course.
In addition to the things to check above, get a way to do a buzz test. Forscan with blue tooth dongle or whatever.
And check the underside of the harness that runs to the 42 pin connector over the driver side valve cover, it can chafe on the VCs and cause shorts.
The odd thing is when the regulator shorted on my truck the oip pressure still fluctuate a little bot for some reason, maybe cranking speed?
I will have to do the buzz test I have a Bluetooth adapter,
Those wires shorting out would only kill one bank of injectors? Unless it shorts the whole IDM and nothing fires which is entirely possible, would I still be hearing something that sounds like injectors clicking?
Ok awesome thanks! I will have to watch those, I probably wont use the IPR if it works after as I dont want it to happen again but at leats this will tell us it is the issue
I didn't see it asked..but are you sure you are getting oil pressure while cranking? Double check your oil in case you haven't...look for oil in your coolant and fuel filter...get some new batteries in there. I had 4.5 on 5 year batts..these things really need a lot of juice to run. A dead cell will wreak havoc. Throwing some simple stuff out there...diagnose then buy parts, not the other way around...you will get there!
I didn't see it asked..but are you sure you are getting oil pressure while cranking? Double check your oil in case you haven't...look for oil in your coolant and fuel filter...get some new batteries in there. I had 4.5 on 5 year batts..these things really need a lot of juice to run. A dead cell will wreak havoc. Throwing some simple stuff out there...diagnose then buy parts, not the other way around...you will get there!
2 new batteries from interstate both tested about 720 CCA,
The HPOP is full of oil and the oil is all the way up to full on the dipstick,
You will learn alot here. Ive been off the site for a while...well...all sites...Got my IDM being rebuilt as we speak and will be going back to all FACTORY stuff...Been chasing my issue for 6 years...no codes, compression checks good...new or repaired wiring, cups...still have an unexplained miss and while everyone swears the IDM should be throwing a code its the last on the list. almost 20 years old and its never been replaced. Running ohnm tests tomorrow. The *****ty part is i tore my rotator cuff sio im one arming it
You will learn alot here. Ive been off the site for a while...well...all sites...Got my IDM being rebuilt as we speak and will be going back to all FACTORY stuff...Been chasing my issue for 6 years...no codes, compression checks good...new or repaired wiring, cups...still have an unexplained miss and while everyone swears the IDM should be throwing a code its the last on the list. almost 20 years old and its never been replaced. Running ohnm tests tomorrow. The *****ty part is i tore my rotator cuff sio im one arming it
Thats pretty cool!
This is a stupid question that you have prolly already been asked,
Have you tried replacing the cam position sensor with a FORD or MOTORCRAFT sensor? Any other brand will cause all sorts of missfire havoc from my little experience,
You will learn alot here. Ive been off the site for a while...well...all sites...Got my IDM being rebuilt as we speak and will be going back to all FACTORY stuff...Been chasing my issue for 6 years...no codes, compression checks good...new or repaired wiring, cups...still have an unexplained miss and while everyone swears the IDM should be throwing a code its the last on the list. almost 20 years old and its never been replaced. Running ohnm tests tomorrow. The *****ty part is i tore my rotator cuff sio im one arming it
Yep, the rough idle miss. As contagious as covid, expensive as a strippers phone number, and about as curable as a case of herpes. Likely contracted from said stripper. Welcome to the club.
Yep, the rough idle miss. As contagious as covid, expensive as a strippers phone number, and about as curable as a case of herpes. Likely contracted from said stripper. Welcome to the club.
I had a awful miss for about 3 months before I did some research and found I got a random CPS when I replaced it, Got a Motorcraft one and all issues were solved,
$20 part making me think I needed $1600 injectors,
