Injection pump question
Tuned
Joined: May 2019
Posts: 480
Likes: 141
From: NJ
6.5 General Motors engines had a setup like what you want. It may be possible to put your input shaft on the pump from a 6.5 GM engine, then hook up a few modules and sensors to make it work. I believe the GM pump uses a different gear mounting, but it looks kinda similar and might be the same. Hydraulic head and mount pattern for the pump body is the same for 6.9/7.3 IDI and 6.5/6.2. Look into it.
There probably isn't an easy solution though, either do a ton of custom work, or get a Powerstroke.
There probably isn't an easy solution though, either do a ton of custom work, or get a Powerstroke.
Last edited by solanum; Aug 6, 2019 at 09:32 PM. Reason: Add more info
Scope Wizard
Joined: May 2019
Posts: 6,530
Likes: 25
at like 6000 feet effective oxygen is 16.6% so if tuned at sea level you will be over fueling ... so as others have said raise the right foot
on another note IF you have the E4OD there is a High Altitude PCM for it.
on another note IF you have the E4OD there is a High Altitude PCM for it.
More Turbo
Joined: Oct 2014
Posts: 697
Likes: 82
From: Alberta Eh
Also I think the IPs on the GM idi engines spin the opposite way to ours, at least that’s what I was told.
Posting Guru
Joined: May 2015
Posts: 2,036
Likes: 5
They sold relocation kits for the brain on the ds4 because originally it's mounted on the side of the ip, although this helped there was still problems.
They also used a laser inside to read the fuel flow, so if you're running dyed diesel or a wmo biofuel that isn't clear or Amber it won't run.
Thread Starter
|
Tuned
Joined: Apr 2018
Posts: 281
Likes: 1
Thank you everyone for your input hm I guess for travel I could look into a powerstroke in the worst case anyway what can I say I have a soft spot for the classics haha
Trending Topics
Scope Wizard
Joined: May 2019
Posts: 6,530
Likes: 25
I don't know why anyone would want to complicate their Life
BTW GM runs same direction as Ford, but I see the Humor in the joke
here is the manual I have on the DS pump IF you just want to learn about it. Hopefully I can attach a file.......
EDIT: oh well, it goes thru the motions of adding the PDF Manual but I don't see that it really attached it
BTW GM runs same direction as Ford, but I see the Humor in the joke
here is the manual I have on the DS pump IF you just want to learn about it. Hopefully I can attach a file.......
EDIT: oh well, it goes thru the motions of adding the PDF Manual but I don't see that it really attached it
FTE Stories
Ford Trucks for Ford Truck Enthusiasts
Top 10 Fords at 2026 Carlisle Ford Nationals
Joe Kucinski
3 Best / 3 Worst Parts of Modern Ford Ownership
Brett Foote
10 Amazing Upgrades That Solve Common Ford Truck Owner Headaches
Pouria Savadkouei
Every 2026 Ford Engine Explained
Brett Foote
10 Ugly Ford Trucks That We Still Kinda Love
Joe Kucinski
10 Things Every Truck Owner NEEDS (2026 Edition)
Michael S. Palmer
Rezvani's Latest Post-Apocalyptic Monster Is a Ford F-150 Raptor Underneath
Verdad Gallardo
Top 10 Most Expensive Ford Trucks Ever Sold on Bring a Trailer
Joe Kucinski
2027 Ford Super Duty Buyer's Guide (Every Model, Engine, & Package)
Brett Foote
Lead Driver
Joined: Apr 2008
Posts: 6,945
Likes: 13
The less basic step, and the clear and obvious winner is to install a turbo, turn the fuel up, then not care what elevation youre at.
FWIW, where i live in ID and OR, i travel between 2k and 4800' all the time, the difference is negligable. Now when i went to the coast however, was like she was runnin on nitrous all the time.
Logistics Pro
Joined: Jun 2017
Posts: 3,985
Likes: 515
From: Edmond, OK
I provide a link in this thread to a DB2 rebuild manual (post #8).
https://www.ford-trucks.com/forums/1...east-want.html
https://www.ford-trucks.com/forums/1...east-want.html
Elder User
Joined: May 2018
Posts: 695
Likes: 22
When these engine first came out, there WAS a high elevation version and sea level version. The sea level version was rated at 195 HP if I remember right, the high altitude version is something like 185 or 165.
Scope Wizard
Joined: May 2019
Posts: 6,530
Likes: 25
I provide a link in this thread to a DB2 rebuild manual (post #8).
https://www.ford-trucks.com/forums/1...east-want.html
https://www.ford-trucks.com/forums/1...east-want.html
I was trying to upload the DS Pump manual I have for the Electronic Controlled Pump.... forums wouldn't do it, maybe you have to be a paid member to upload Files, it could be my file size is too Large.
Anyway... I found a similar manual here just not as extensive... http://www.stanadyne.com/dealerporta...nual/99646.pdf
