Vacuum lines
So I have a 1996 f150 with a 4.9. Does anyone have a picture of where all the vacuum lines go? I thought I had enough pictures of mine before I took it apart but it's been awhile and I can't seem to figure out where they all go. Specifically on the drivers side of the engine where the three selenoids are mounted to the valve cover.
Elder User
Joined: Sep 2018
Posts: 735
Likes: 8
From: NC
https://www.ford-trucks.com/forums/1...es-photos.html that might help.
look under your hood for the diagram also.
look under your hood for the diagram also.
Thread Starter
|
Cross-Country
Joined: Feb 2017
Posts: 99
Likes: 2
From: New Jersey/Delaware
I have a new radiator support so the diagram is gone. I need a close up of the tad/tab sensors and their lines
https://www.ford-trucks.com/forums/1...es-photos.html that might help.
look under your hood for the diagram also.
look under your hood for the diagram also.
Fleet Mechanic
Joined: Mar 2017
Posts: 1,371
Likes: 138
From: Manassas, VA
I have a 1996. I would be happy to take some photos tomorrow after work if no one chimes in before then!
Thread Starter
|
Cross-Country
Joined: Feb 2017
Posts: 99
Likes: 2
From: New Jersey/Delaware
That would be awesome! Thank you
