1948 - 1956 F1, F100 & Larger F-Series Trucks Discuss the Fat Fendered and Classic Ford Trucks

Timing chain removal


  #16
Old 09-23-2015, 03:57 PM
jrockdiddy's Avatar
jrockdiddy
jrockdiddy is offline
Posting Guru
Thread Starter
Join Date: Dec 2012
Location: Scottsdale, AZ
Posts: 1,226
jrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to behold




  #17
Old 09-23-2015, 04:05 PM
ALBUQ F-1's Avatar
ALBUQ F-1
ALBUQ F-1 is online now
Post Fiend
Join Date: Jul 2004
Location: NM
Posts: 24,099
ALBUQ F-1 has a superb reputationALBUQ F-1 has a superb reputationALBUQ F-1 has a superb reputationALBUQ F-1 has a superb reputationALBUQ F-1 has a superb reputationALBUQ F-1 has a superb reputationALBUQ F-1 has a superb reputationALBUQ F-1 has a superb reputationALBUQ F-1 has a superb reputationALBUQ F-1 has a superb reputationALBUQ F-1 has a superb reputation
From what little detail is in the invoice, it appears a lot was to be done by Owner. The blame may not lie with the shop. Jrock, what parts are shown in the left hand side of the invoice, under the M/C slip? If galley plugs are shown...

I have to wonder why one cylinder was sleeved?



  #18
Old 09-23-2015, 04:30 PM
jrockdiddy's Avatar
jrockdiddy
jrockdiddy is offline
Posting Guru
Thread Starter
Join Date: Dec 2012
Location: Scottsdale, AZ
Posts: 1,226
jrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to behold
One charge was harmonic balancer, which would make me think the machine shop installed timing cover and timing chain

  #19
Old 09-23-2015, 04:31 PM
jrockdiddy's Avatar
jrockdiddy
jrockdiddy is offline
Posting Guru
Thread Starter
Join Date: Dec 2012
Location: Scottsdale, AZ
Posts: 1,226
jrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to behold
Look better?


  #20
Old 09-23-2015, 05:24 PM
ALBUQ F-1's Avatar
ALBUQ F-1
ALBUQ F-1 is online now
Post Fiend
Join Date: Jul 2004
Location: NM
Posts: 24,099
ALBUQ F-1 has a superb reputationALBUQ F-1 has a superb reputationALBUQ F-1 has a superb reputationALBUQ F-1 has a superb reputationALBUQ F-1 has a superb reputationALBUQ F-1 has a superb reputationALBUQ F-1 has a superb reputationALBUQ F-1 has a superb reputationALBUQ F-1 has a superb reputationALBUQ F-1 has a superb reputationALBUQ F-1 has a superb reputation
Much better! Are you going to check the bearings?

The only labor charges I see are for pure machine work. "Assy prep & tap holes etc" for $32 surely doesn't cover assembly of the whole engine.

  #21
Old 09-23-2015, 05:56 PM
jrockdiddy's Avatar
jrockdiddy
jrockdiddy is offline
Posting Guru
Thread Starter
Join Date: Dec 2012
Location: Scottsdale, AZ
Posts: 1,226
jrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to behold
Yes gonna check the bearings. I thought about putting a big cam in it since it's easily accessible, but I'd also have to do lifters. Also gonna pull the intake manifold to check the oil galley plug in the back

  #22
Old 09-23-2015, 05:57 PM
jrockdiddy's Avatar
jrockdiddy
jrockdiddy is offline
Posting Guru
Thread Starter
Join Date: Dec 2012
Location: Scottsdale, AZ
Posts: 1,226
jrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to behold
Originally Posted by schoo View Post
I live in the sac area who was it


Schoo, do u know the place?

  #23
Old 09-23-2015, 09:36 PM
truckeemtnfords
truckeemtnfords is offline
Postmaster
Join Date: Nov 2006
Location: Truckee, CA
Posts: 2,617
truckeemtnfords has much to be proud oftruckeemtnfords has much to be proud oftruckeemtnfords has much to be proud oftruckeemtnfords has much to be proud oftruckeemtnfords has much to be proud oftruckeemtnfords has much to be proud oftruckeemtnfords has much to be proud oftruckeemtnfords has much to be proud of
On that invoice I do not see a line item for assembly. I bet it was put together by the owner which would explain all the oil plugs missing. When I built engines at the speed shop some owners wanted to assemble their engine because they did not want to spend the $120 (early to mid eighties) for me to assemble it. More than once they failed to install at least one oil galley plug. Most all plug kits don't come with all the plugs needed when a competent shop removes them all for hot tanking. My shop removed them all so that you got a completely clean engine.

Based on the invoice the shop did not build the engine. Buyer beware.

  #24
Old 09-23-2015, 10:07 PM
schoo's Avatar
schoo
schoo is offline
Postmaster
Join Date: Mar 2012
Location: placer county usa?
Posts: 3,523
schoo is a splendid one to beholdschoo is a splendid one to beholdschoo is a splendid one to beholdschoo is a splendid one to beholdschoo is a splendid one to beholdschoo is a splendid one to beholdschoo is a splendid one to beholdschoo is a splendid one to behold
Originally Posted by jrockdiddy View Post
Schoo, do u know the place?
No I don't know the place and I agree with the others PO assambled

  #25
Old 09-25-2015, 01:38 PM
jrockdiddy's Avatar
jrockdiddy
jrockdiddy is offline
Posting Guru
Thread Starter
Join Date: Dec 2012
Location: Scottsdale, AZ
Posts: 1,226
jrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to behold
I checked rod bearings with someone that has more knowledge than me. Everything looked good and had correct bearings. I only ran the motor for a short period. Once I put everything back on, gonna prime oil pump and check pressure. If it still looks low, I'll check oil galley plug under intake manifold

  #26
Old 09-25-2015, 03:30 PM
truckeemtnfords
truckeemtnfords is offline
Postmaster
Join Date: Nov 2006
Location: Truckee, CA
Posts: 2,617
truckeemtnfords has much to be proud oftruckeemtnfords has much to be proud oftruckeemtnfords has much to be proud oftruckeemtnfords has much to be proud oftruckeemtnfords has much to be proud oftruckeemtnfords has much to be proud oftruckeemtnfords has much to be proud oftruckeemtnfords has much to be proud of
Sounds good but it is only 12 bolts and a gasket to pull the manifold and verify that plug is there. It would be peace of mind for me considering the obvious ones the PO did not install. Besides if it is there I bet it ain't staked. Plus if you check now you would not have to re-drain the cooling system and all the other little things that you would have to do if you find an issue later.

On another note you do not have to assemble everything to prime the pump by hand to verify oil pressure. You can do it with the timing cover, intake and valve covers off.

  #27
Old 10-05-2015, 02:06 PM
jrockdiddy's Avatar
jrockdiddy
jrockdiddy is offline
Posting Guru
Thread Starter
Join Date: Dec 2012
Location: Scottsdale, AZ
Posts: 1,226
jrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to behold
Update,
primed oil pump today, got 30 lbs of pressure. Getting ready to pull intake manifold. pulled a valve cover and didn't see any oil coming from rockers....Here's a quick video...

the drill is corded and puts out 3,000 RPM's..


  #28
Old 10-05-2015, 03:51 PM
jrockdiddy's Avatar
jrockdiddy
jrockdiddy is offline
Posting Guru
Thread Starter
Join Date: Dec 2012
Location: Scottsdale, AZ
Posts: 1,226
jrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to behold







Originally Posted by jrockdiddy View Post
Update,
primed oil pump today, got 30 lbs of pressure. Getting ready to pull intake manifold. pulled a valve cover and didn't see any oil coming from rockers....Here's a quick video...

the drill is corded and puts out 3,000 RPM's..

Oil pressure - YouTube

  #29
Old 10-05-2015, 04:50 PM
jrockdiddy's Avatar
jrockdiddy
jrockdiddy is offline
Posting Guru
Thread Starter
Join Date: Dec 2012
Location: Scottsdale, AZ
Posts: 1,226
jrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to beholdjrockdiddy is a splendid one to behold
Finally, capped the last missing plug and away we go!!!!


  #30
Old 10-05-2015, 06:00 PM
Scotty's 52 F3's Avatar
Scotty's 52 F3
Scotty's 52 F3 is offline
Posting Guru
Join Date: Aug 2015
Location: Marana, Arizona
Posts: 1,455
Scotty's 52 F3 has a great reputation on FTE.Scotty's 52 F3 has a great reputation on FTE.Scotty's 52 F3 has a great reputation on FTE.Scotty's 52 F3 has a great reputation on FTE.Scotty's 52 F3 has a great reputation on FTE.
Glad you got it done and no damage. Other than gaskets!
