Bed Cap Hoist System
I've been doing some research on the net for a bed cap hoist system. I was hoping others on this forum would be willing to share their ideas, systems, and photos.
I was hoping to have a ceiling mounted hoist to lift the cap as I probably won't have any help removing the cap.
I have ordered a Leer 100XR with a ceiling locker and roof rack.
Thank you in advance for your assistance.
I was hoping to have a ceiling mounted hoist to lift the cap as I probably won't have any help removing the cap.
I have ordered a Leer 100XR with a ceiling locker and roof rack.
Thank you in advance for your assistance.
Elder User
Joined: Aug 2007
Posts: 914
Likes: 1
From: Saskatoon, SK, CA
Two ceiling bike lifts may do it. If mounted correctly to the ceiling they may handle the weight and be able to be operated by one person. It's a low cost option but I'm thinking they wouldn't handle the weight if the cap. What's your total weight? On second thought they only handle 50 lbs each so not an option.
But something like it would be good with a higher weight rating. They would probably work for a flat fiberglass bed topper.
http://www.amazon.com/gp/aw/d/B00006...&robot_redir=1
But something like it would be good with a higher weight rating. They would probably work for a flat fiberglass bed topper.
http://www.amazon.com/gp/aw/d/B00006...&robot_redir=1
Thread Starter
|
Senior User
Joined: Jun 2010
Posts: 161
Likes: 0
I think it will weigh a couple hundred pounds but not sure.
It will have a ceiling locker. So that will be a bit heavier than a shell without one: http://www.leer.com/Videos
I'll have it installed in a week, so I'll get back to all and advise.
I've been looking at electric winch type systems so I could use it for other purposes as well. Hopefully someone has a hoist system they want to show off so I don't have to be the topic trailblazer.
I'll have it installed in a week, so I'll get back to all and advise.
I've been looking at electric winch type systems so I could use it for other purposes as well. Hopefully someone has a hoist system they want to show off so I don't have to be the topic trailblazer.
Posting Guru
Joined: Apr 2011
Posts: 2,345
Likes: 0
Elder User
Joined: Aug 2007
Posts: 914
Likes: 1
From: Saskatoon, SK, CA
Harbor Freight has a good priced option with two different electric hoist models. One for 880 lbs and one for 1,300 lbs which is sufficient capacity for your topper. Just need to rig a 4 point attachment system that won't scratch/damage the topper.
Electric Hoist - 880 Lb. Capacity Electric Hoist
1300 lb. Electric Hoist with Remote Control
Electric Hoist - 880 Lb. Capacity Electric Hoist
1300 lb. Electric Hoist with Remote Control
Elder User
Joined: Aug 2007
Posts: 914
Likes: 1
From: Saskatoon, SK, CA
And another option - they want over $200 for the higher capacity one at the bottom (#7806) but may be easier to mount than an electric hoist.
Garage Strategies™ - Harken
Garage Strategies™ - Harken
Trending Topics
Thread Starter
|
Senior User
Joined: Jun 2010
Posts: 161
Likes: 0
Thank you for the suggestions
I hadn't seen those options. I saw some interesting concepts on you tube but nothing overly convincing to indicate that one option was better than the others. I like the electric hoist options.
Here's an idea that I hadn't thought through yet. I have an old garage door opener. I'm not sure that it could handle the the weight though. Thoughts?
Here's an idea that I hadn't thought through yet. I have an old garage door opener. I'm not sure that it could handle the the weight though. Thoughts?
FTE Stories
Ford Trucks for Ford Truck Enthusiasts
Top 6 Best Deals Available on New Fords & Lincolns Right Now
Brett Foote
This Hennessey Takes the Expedition Tremor's Off-Roading Capability to the Next Level
Verdad Gallardo
Top 10 Fords at 2026 Carlisle Ford Nationals
Joe Kucinski
3 Best / 3 Worst Parts of Modern Ford Ownership
Brett Foote
10 Amazing Upgrades That Solve Common Ford Truck Owner Headaches
Pouria Savadkouei
Every 2026 Ford Engine Explained
Brett Foote
10 Ugly Ford Trucks That We Still Kinda Love
Joe Kucinski
10 Things Every Truck Owner NEEDS (2026 Edition)
Michael S. Palmer
Rezvani's Latest Post-Apocalyptic Monster Is a Ford F-150 Raptor Underneath
Verdad Gallardo
Elder User
Joined: Aug 2007
Posts: 914
Likes: 1
From: Saskatoon, SK, CA
I hadn't seen those options. I saw some interesting concepts on you tube but nothing overly convincing to indicate that one option was better than the others. I like the electric hoist options.
Here's an idea that I hadn't thought through yet. I have an old garage door opener. I'm not sure that it could handle the the weight though. Thoughts?
Here's an idea that I hadn't thought through yet. I have an old garage door opener. I'm not sure that it could handle the the weight though. Thoughts?
Senior User
Joined: Aug 2012
Posts: 172
Likes: 1
From: Wisconsin
When my wife and I decided to switch from a travel trailer to a fifth wheel I has to do something with my cap too. Last thing I wanted to do is lay it in the weeds somewhere behind the house. I found a person online that did some similar to what I have done. I ordered most of it from Harbor Freight but I am sure you could find most of it at a good hardware store. I think Harbor Freight is the only place to get the winch for the wall. The 2x4's are screwed into the roof trusses. I have never let it down since I raised it up five years ago. The only advice that I could give is to cut the eye bolts off that hang down past the nut under the 2x4. I didn't and it scratched the paint on my truck box but that's what I get when I rush things. I had the lumber laying around the house already and probably spent less than $100 on the rest of the hardware. Good Luck!!
Senior User
Joined: Aug 2012
Posts: 172
Likes: 1
From: Wisconsin
The 2x4's on ceiling are perpendicular to the roof trusses above. It allowed me more options of where to put the pullies. I also think it helps disperse the weight as well.
Thread Starter
|
Senior User
Joined: Jun 2010
Posts: 161
Likes: 0
Inside the center section of the shell..
There appears to be a piece of wood going side-to-side, and then it appears there is a piece of wood attached to that wood member going to the back of the shell, and it appears that attaches to the rear supporting plank. I wasn't sure if the center piece of wood was to prevent the shell from flexing because it didn't seem to be supporting the weight of the shell.
I also noticed that you used the bed mounts to secure the shell to the supporting piece of wood at the rear. I may have overlooked that idea without having seen your set up.
I also noticed that you used the bed mounts to secure the shell to the supporting piece of wood at the rear. I may have overlooked that idea without having seen your set up.
Senior User
Joined: Aug 2012
Posts: 172
Likes: 1
From: Wisconsin
The wood you see in the cap is a shelf that I used along with the cap. I am a carpenter by trade, I always kept coffee cans with different fasteners along with various hand tools on the shelf. It helped to keep fewer thing on the floor of the truck bed. Yes the clamps worked well keeping the cap fastened to the 2x's.
