Ford Keyless Entry Installation
I recieved a christmas present early today! It is a Ford keyless entry system from fordaccessories.com. Obviously I'm not going to install it tonight but would like to get it done this weekend. The only problem I have with getting it done this weekend is that there were no installation instructions included. the back of the module does tell what each color wire goes to. Will these colors match up to the colors of the wires on the truck.
Has anyone intalled one of these? Is there anything I should look out for?
Has anyone intalled one of these? Is there anything I should look out for?
Senior User
Joined: Sep 2006
Posts: 174
Likes: 0
From: Savannah
I put a Ford keless entry on my truck last year not to bad i have the book but will be sat night . send me a list of what you need . Mine had the remote start and a bunch of other stuff. help if i can .
Thread Starter
|
Senior User
Joined: Jan 2007
Posts: 287
Likes: 0
From: York, SC
Mine is only the keyless entry. It came with a fairly large wire harness that runs from the module. There are quit a few wires that these run to. I really only need to know what color wires on the truck that these hook up to (do they match the wire harness colors). Also where is the best place to mount the module. The only other thing that is puzzling me is the module has slots for fuses. These slots are not labeled well and in a few cases there are three slots for one fuse (by this I mean that there are three places where one of the legs of the fuse could plug in so i guess there is really two places the fuse could plug in.)
Thanks in advance
Thanks in advance
Senior User
Joined: Sep 2006
Posts: 174
Likes: 0
From: Savannah
Trending Topics
Thread Starter
|
Senior User
Joined: Jan 2007
Posts: 287
Likes: 0
From: York, SC
Originally Posted by pmbmax
if i remeber those are for wires for other options. post pic if you can.
here is the wiring harness that came with it
FTE Stories
Ford Trucks for Ford Truck Enthusiasts
10 Best Ford Truck Engines We Miss the Most!
Joe Kucinski
2026 Shelby F-150 Off-Road: Better Than a Raptor R?
Brett Foote
2027 Super Duty Carhartt Package First Look: 12 Things You NEED to Know!
Michael S. Palmer
10 Most Surprising 2026 Ford Truck Features!
Joe Kucinski
Top 10 Ford Trucks Coming to Mecum Indy 2026
Brett Foote
5 Best / 5 Worst Ford Truck Wheels of All Time
Joe Kucinski
Ford Super Duty: 5 Things Owners LOVE, 5 Things They LOATHE!
Joe Kucinski
Every 2026 Ford Truck Engine RANKED from WORST to FIRST!
Michael S. Palmer
The Best F-150 Deal of Every Trim Level (XL through Raptor)
Joe Kucinski
Thread Starter
|
Senior User
Joined: Jan 2007
Posts: 287
Likes: 0
From: York, SC
Originally Posted by pmbmax
I have a pic of the color and location of all the wires in your truck can you send me an email i can send it to are tell me how you put those up . thanks phillip
Senior User
Joined: Sep 2006
Posts: 174
Likes: 0
From: Savannah
Thread Starter
|
Senior User
Joined: Jan 2007
Posts: 287
Likes: 0
From: York, SC
Originally Posted by pmbmax
sent 3 pics Be fro pmbmax@hotmail.com
Thanks again
Thread Starter
|
Senior User
Joined: Jan 2007
Posts: 287
Likes: 0
From: York, SC
I've started trying to figure out whaich wires go where and where the best place to tie into them is. I have a Haynes Manual that I use for my truck but it is for a 99-02 Superduty and mine is a 03. Will the wire colors in the diagrams in the book be the same for my 03.
Also the book shows significantly different diagrams for the 99-01 and for 02. I think that mine will like the 02 diagram but there is not an 02 diagram without keyless entry. It looks like basically I need to put the system I have in the position that the vehicle security module is in the book. Will my truck have a VSM even though it does not have keyless entry? if it does I think this will be the best place to tie into all of the wire I need.
Also the book shows significantly different diagrams for the 99-01 and for 02. I think that mine will like the 02 diagram but there is not an 02 diagram without keyless entry. It looks like basically I need to put the system I have in the position that the vehicle security module is in the book. Will my truck have a VSM even though it does not have keyless entry? if it does I think this will be the best place to tie into all of the wire I need.
Thread Starter
|
Senior User
Joined: Jan 2007
Posts: 287
Likes: 0
From: York, SC
Ok. Here where I'm at. I finally got the correct wiring diagrams. The only trouble I'm having figuring them out is there are two relays in the diagram. One to lock the door and one to unlock the doors. The diagram that applies to me does not say what these relays are but a diagram for another application says they are not supplied and they are ford part number YL3Z-19G390-AA. Is there a spot in the fuse pox that these relays will plug in? There are 3 open slots that the owners manual says are not used. I pulled one of the other relays from the panel (Part Number FOAB-14B192-AA). The numbers on each pin match the pin numbers in my wiring diagram. Do these two part numbers cross reference?
