89 XLT Trans??
Just bought another truck.... 89F150 XLT. It's pretty rusty but the drive train feels/sounds good and the money was right... at least for me.
The door tag is hard to read and I can't tell what the trans code is... it looks like a "T", but I don't see that code in my chart. I know it is a 302 and axle code is "H9" which I should be a 3.55 LS. Previous owner says it is an OD tranny ... it is NOT the one with a button on the dash. Gear selector reads P-R-N-D-2-1
Of course I have no way of knowing if column or tranny has been replaced.
Any help appreciated!
The door tag is hard to read and I can't tell what the trans code is... it looks like a "T", but I don't see that code in my chart. I know it is a 302 and axle code is "H9" which I should be a 3.55 LS. Previous owner says it is an OD tranny ... it is NOT the one with a button on the dash. Gear selector reads P-R-N-D-2-1
Of course I have no way of knowing if column or tranny has been replaced.
Any help appreciated!
Senior User
Joined: Apr 2006
Posts: 447
Likes: 0
From: youngstown ohio
someone could have changed dash so if has aod which is what my truck had t trans code ur second gear is drive and drive is overdrive best way to tell is drive in drive at between 45-50 u will feel a shift to overdrive and truck should lug a lil i have same setup in mine at 45 od kicks in when i let off gas slightly and is noticable if urs does it then just drive in second because od trans has p-r-n-od-d-1 this is what my dash has
Ford Parts Specialist
Joined: Nov 2006
Posts: 88,826
Likes: 787
From: Simi Valley, CA
He asked this same question in the Iowa Chapter Forum. The question was answered, it's an AOD.
The answer came from the: 1980/89 Ford Light Truck Parts Catalog.
Automatic transmission application chart, Section A70, page 26.
The answer came from the: 1980/89 Ford Light Truck Parts Catalog.
Automatic transmission application chart, Section A70, page 26.
Last edited by NumberDummy; Apr 25, 2007 at 05:49 PM.
Thread Starter
|
Elder User
Joined: Dec 2003
Posts: 633
Likes: 1
Thanks all.... I thought it got lost here as it flew to the second page quickly with only a view or 2. Sorry i doubt that folks would go back that far. I'll be more patient next time.
Appreicate the info here as well as I thought the shift indicatiors were odd not showing OD anywhere.
I'm going to go ahead and crawl under it. I really suspect this thing have had parts swapped in and out of it. I remember seeing the pan shape to identify.
Appreicate the info here as well as I thought the shift indicatiors were odd not showing OD anywhere.
I'm going to go ahead and crawl under it. I really suspect this thing have had parts swapped in and out of it. I remember seeing the pan shape to identify.
Mountain Pass
Joined: Dec 2005
Posts: 206
Likes: 0
From: Dover AFB / Harrisburg PA
Trending Topics
Thread Starter
|
Elder User
Joined: Dec 2003
Posts: 633
Likes: 1
FTE Stories
Ford Trucks for Ford Truck Enthusiasts
Top 10 Fords at 2026 Carlisle Ford Nationals
Joe Kucinski
3 Best / 3 Worst Parts of Modern Ford Ownership
Brett Foote
10 Amazing Upgrades That Solve Common Ford Truck Owner Headaches
Pouria Savadkouei
Every 2026 Ford Engine Explained
Brett Foote
10 Ugly Ford Trucks That We Still Kinda Love
Joe Kucinski
10 Things Every Truck Owner NEEDS (2026 Edition)
Michael S. Palmer
Rezvani's Latest Post-Apocalyptic Monster Is a Ford F-150 Raptor Underneath
Verdad Gallardo
Top 10 Most Expensive Ford Trucks Ever Sold on Bring a Trailer
Joe Kucinski
2027 Ford Super Duty Buyer's Guide (Every Model, Engine, & Package)
Brett Foote
Thread Starter
|
Elder User
Joined: Dec 2003
Posts: 633
Likes: 1
I quit updating mine. Except mine are all beaters. lol - I find so many out there that I bought a tow dolly. I quit dreaming about projects... I have probably owned 10 trucks in the last 2 years. I was down to 2 truck Tuesday morning, but I am up to 4 now. Tow dolly runs on Tuesday and Wednesday nights.
Thread Starter
|
Elder User
Joined: Dec 2003
Posts: 633
Likes: 1
geez - it's confirmed. I'm an idiot. Column markings i posted were from another truck. I counted pan bolt, looked at the column again in the light, and the door tag says "T". Everything matches up to AOD as Numberdummy stated.
