Exhaust manifold question
Thread Starter
|
Trailering
Joined: Jun 2024
Posts: 17
Likes: 0
Exhaust manifold question
I have a 1983 F150 w/4.9L WITH ALL THE EMISSIONS AND SMOG CRAP REMOVED. My old exhaust manifold had a crack in it, so I purchased a new one. The new manifold has 2 plugs in it and one seems to have a small hole drilled in it. Is this for the EGR valve? And if so can I remove it and insert a plug in it's place since I don't run an EGR? And if not, what is this plug with a hole in it? Thanks in advance.
Moderator
Joined: Jan 2001
Posts: 56,984
Likes: 2,738
From: Virginia
It may be the hole for the choke tube. If that is the case, you could leave the hole open and no harm would be done. You could squirt a can of brake cleaner in the hole, and see if it comes out inside the manifold, or just goes right on through to another small hole. If it goes right on through, it's the choke tube hole.
Lead Driver
Joined: Jun 2013
Posts: 5,667
Likes: 1,159
From: Tolland, CT
Trending Topics
FTE Legend
Joined: Nov 2015
Posts: 30,912
Likes: 4,123
From: Angier, NC
Because I am a "show me" type
If it was not so cold I would check the log manifold in the garage.
I can only think of the small holes for the choke tubes and the large hole for the EGR tube.
So I am guessing it is the EGR. IIRC the old manifolds uses adapter and think the manifold side is pipe thread 1/2" or 3/4" at most.
Dave ----
If it was not so cold I would check the log manifold in the garage.
I can only think of the small holes for the choke tubes and the large hole for the EGR tube.
So I am guessing it is the EGR. IIRC the old manifolds uses adapter and think the manifold side is pipe thread 1/2" or 3/4" at most.
Dave ----
FTE Stories
Ford Trucks for Ford Truck Enthusiasts
Top 10 Most Expensive Ford Trucks Ever Sold on Bring a Trailer
Joe Kucinski
2027 Ford Super Duty Buyer's Guide (Every Model, Engine, & Package)
Brett Foote
Top 10 Ford Truck Tragedies
Joe Kucinski
AEV FXL Super Duty - the Super Duty Raptor Ford Doesn't Make
Brett Foote
Lobo Vs Lobo: Proof the F-150 Lobo Should Be Even Lower!
Michael S. Palmer
Ford's 2001 Explorer Sportsman Concept Looks For a New Home
Verdad Gallardo
10 Best Ford Truck Engines We Miss the Most!
Joe Kucinski
2026 Shelby F-150 Off-Road: Better Than a Raptor R?
Brett Foote
2027 Super Duty Carhartt Package First Look: 12 Things You NEED to Know!
Michael S. Palmer
Thread Starter
|
Trailering
Joined: Jun 2024
Posts: 17
Likes: 0
exhaust manifold
Thanks to all responders, it is the choke hole. No need to plug the hole as it does not go into the exhaust chamber. If I had used common sense I would have figured it out sooner than later since there is a similar hole on the top side of the manifold for an optional position to use.
Moderator
Joined: Jan 2001
Posts: 56,984
Likes: 2,738
From: Virginia
Thanks to all responders, it is the choke hole. No need to plug the hole as it does not go into the exhaust chamber. If I had used common sense I would have figured it out sooner than later since there is a similar hole on the top side of the manifold for an optional position to use.
