Excursion Gauge Lights
So recently installed a US Speedo Daytona gauge face. I figured while I had it out I'd do the back lights too and started with a set of red LEDs. After getting it back in the only lights I had were the blinkers and right side gauges. Put some regular bulbs back in with the same results. Interestingly, had a speedo light work momentarily on the way to work Saturday.
So now my challenge, what I need help with, is going to be powering the gauge lights while they're out of the truck. Which plug(s) and which wires are my back light's power and ground? Any tips and guidance appreciated.
So now my challenge, what I need help with, is going to be powering the gauge lights while they're out of the truck. Which plug(s) and which wires are my back light's power and ground? Any tips and guidance appreciated.
Moderator
Joined: Jan 2001
Posts: 57,005
Likes: 2,750
From: Virginia
When you pull the cluster, look at the large plug or plugs, there will be a lightblue/red wire in one of the slots. That is the illumination wire. Count over how many slots, that should be it. You should be able to follow it on the circuit traces, and it should hit just about every bulb on the circuit board for illumination.
