82 Ford e350 wiring diagram needed
Thread Starter
|
5th Wheeling
Joined: Sep 2022
Posts: 31
Likes: 0
82 Ford e350 wiring diagram needed
82 Ford e350,no brake lights and rear passenger signal is out. Running lights signal working both front and only drivers rear.
No horn and heater fan works some times if I play with the fuse, no 4 way emergency flashers.
Anyone have the wiring diagram for an 82 e350 with a 5.8 351
No horn and heater fan works some times if I play with the fuse, no 4 way emergency flashers.
Anyone have the wiring diagram for an 82 e350 with a 5.8 351
Fleet Owner
Joined: Aug 2010
Posts: 21,253
Likes: 1,656
From: Reynoldsburg, Ohio
If you'd like to have the full printed version of the EVTM here's a great deal on eBay: 1984 E-Series EVTM.
I have no affiliation, just trying to help. I couldn't even begin working on something this age without such a manual.
I have no affiliation, just trying to help. I couldn't even begin working on something this age without such a manual.
Thread Starter
|
5th Wheeling
Joined: Sep 2022
Posts: 31
Likes: 0
That's for vacuum line diagram and for a 1984.
I'm looking for wiring diagrams for a 1982 Ford e350.
I don't play with paypal or ebay,or amazon or anything online shopping.
Won't do online shopping on a boat,not on a train,not even on a plane. I won't shop online sam iam.
Thank you anyway.
Cheers.
I'm looking for wiring diagrams for a 1982 Ford e350.
I don't play with paypal or ebay,or amazon or anything online shopping.
Won't do online shopping on a boat,not on a train,not even on a plane. I won't shop online sam iam.
Thank you anyway.
Cheers.
Fleet Owner
Joined: Aug 2010
Posts: 21,253
Likes: 1,656
From: Reynoldsburg, Ohio
That's for vacuum line diagram and for a 1984.
I'm looking for wiring diagrams for a 1982 Ford e350.
I don't play with paypal or ebay,or amazon or anything online shopping.
Won't do online shopping on a boat,not on a train,not even on a plane. I won't shop online sam iam.
Thank you anyway.
Cheers.
I'm looking for wiring diagrams for a 1982 Ford e350.
I don't play with paypal or ebay,or amazon or anything online shopping.
Won't do online shopping on a boat,not on a train,not even on a plane. I won't shop online sam iam.
Thank you anyway.
Cheers.
Thread Starter
|
5th Wheeling
Joined: Sep 2022
Posts: 31
Likes: 0
Well I dug around in my storage and found this manual,it has what I needed inside.
I got my brake lights working,All signal lights and running lights working.
Still can't figure out why no horn,there is power coming into the steering wheel for it and I still need to get my marker lights going again,plus I got the interior light working just before I got the brake lights working,then the interior light stopped working???
I have power to the stereo but when I turn on the stereo power nothing happens,but the test light goes on if I touch it to the stereo case and the test light goes out if I turn the stereo power off?????
