Wheels and bolt patterns
I have a 52 M3 that I have added IFS (Mustang) front 5 on 4.75 and a 99 F150 rear 5 on 5.5. I made my bed and I'm using Fiberglass fenders from BeBop. I would like to be able to use the same bolt pattern on both front and back. The back wheel is very tight about 1" inside clearance and 1" outside clearance. I have 8 x16" rims and pretty tall sidewalls. I had to trim the fender opening to be able to change tires. Is there a way to have the axles and rotors re drilled for the 5 on 4.75. what have others done?
Thanks in Advance
Don52M3
Thanks in Advance
Don52M3
Hotshot
Joined: Oct 2009
Posts: 16,153
Likes: 4,751
From: Burbank, WA
You can have custom axles made with the 5 on 4.75 bolt pattern, but that could get spendy. With the large center hub on the truck axles, I'm not sure if they can be turned down and drilled to fit the chevy wheels. I believe there are rotors with the 5 on 5.5 Ford truck pattern that with the right bearing combination will fit the MII spindles. You might look into that as a less expensive alternative. It may not answer your question completely in the manner you asked, but it's an idea I thought I'd throw out.
Fleet Mechanic
Joined: Feb 2015
Posts: 1,662
Likes: 111
From: southwest missouri
I don't know what size rim you want to use (sounds like 16) . I bought some wheels from a tire and rim shop and they are pre drilled for 4.3/4 and 5.5 1/2. Now the mustang 2 front that I am using comes with the smaller pattern so I ordered the larger pattern for a couple extra bucks my rear end is the bigger pattern. Now after getting all of this I find out that I could use the wheels on the either front or back. I have thrown some money away because of ignorance on my part. I used to buy parts that I think I would need down the road just to fine out that I did not need them. Like some of the builders on this site tell you to make a plan and stick to it . It will save you money in the long run. Good luck on the build.
Last edited by artscott61; Apr 29, 2019 at 07:50 AM. Reason: spelling
Cargo Master
Joined: Apr 2005
Posts: 3,337
Likes: 165
From: Harpswell Maine
The available dog dish type rims come in either the 5 x 5 1/2 or the dual which is 5 x 4 3/4 and 5 x 5 iirc. You can't get a dual pattern with 5 x 5 1/2 and 5 x 4 3/4 at least in the dog dish style rims. I have the same combination. I have AAA and do not carry a spare. I do have an old adapter for 5 x 5 1/2 to 5 x 4 3/4. which I probably should carry in the truck.
Thread Starter
|
Mountain Pass
Joined: Jul 2017
Posts: 209
Likes: 0
From: Port Orange, Fl
After a lot of internet searches I have come to that conclusions. Be careful on the Internet, got a virus that wiped out my drives today.
thanks for the help
Don52M3
thanks for the help
Don52M3
Trending Topics
Ford Parts Specialist
Joined: Nov 2006
Posts: 88,826
Likes: 784
From: Simi Valley, CA
What year Mustang has 5 on 4.75 wheels?
FTE Stories
Ford Trucks for Ford Truck Enthusiasts
AEV FXL Super Duty - the Super Duty Raptor Ford Doesn't Make
Brett Foote
Lobo Vs Lobo: Proof the F-150 Lobo Should Be Even Lower!
Michael S. Palmer
Ford's 2001 Explorer Sportsman Concept Looks For a New Home
Verdad Gallardo
10 Best Ford Truck Engines We Miss the Most!
Joe Kucinski
2026 Shelby F-150 Off-Road: Better Than a Raptor R?
Brett Foote
2027 Super Duty Carhartt Package First Look: 12 Things You NEED to Know!
Michael S. Palmer
10 Most Surprising 2026 Ford Truck Features!
Joe Kucinski
Top 10 Ford Trucks Coming to Mecum Indy 2026
Brett Foote
5 Best / 5 Worst Ford Truck Wheels of All Time
Joe Kucinski
Thread Starter
|
Mountain Pass
Joined: Jul 2017
Posts: 209
Likes: 0
From: Port Orange, Fl
The IFS was bought from Speedway or Jegs I don't remember and the 99 F150 came out of a salvage yard from a 99 Ford F150 don't know what to tell you other than that. If you look up the rim they give you both metric and US measurements .
Don52M3
Tuned
Joined: Jul 2004
Posts: 263
Likes: 2
From: Moorhead, MN
99 f150 would be 5X135mm pattern(or a hair bigger than 5x5 5/16") It would be hard to find adaptors, or even wheels to fit that pattern, as it was only used on 97-03 half ton fords. Might be cheaper/easier/faster to dump that rear axle and go with and explorer or s10 to solve the bolt pattern problem.
Ford Parts Specialist
Joined: Nov 2006
Posts: 88,826
Likes: 784
From: Simi Valley, CA
No Econoline (E100/350) of any year has metric wheels.
Thread Starter
|
Mountain Pass
Joined: Jul 2017
Posts: 209
Likes: 0
From: Port Orange, Fl
It is possible. I have a picture of the windshield with the insurance company info on the truck. I'll look and see if I can find it. My computer took a bit and I'm working off a laptop that doesn't have all my info on it.
Thanks
Don52M3
Thanks
Don52M3
