Fuel system help
I have a 1977 Ford F-250 with two gas tanks and I have a painless wiring harness well the harness only has one wire for one tank so I called painless wiring and they couldn’t help me with anything so I was wondering if anyone ran into this problem as well or just had to wire it themselves. I can’t find a wiring diagram I understand so I need severe help I have to wire both sending units and the fuel tank switch and selecter

Reply
0
Old Sep 14, 2020 | 01:30 PM
Share
  #2
77&79F250's Avatar
77&79F250
Moderator & parts slinger
Veteran: Army
15 Year Member
Community Builder
Liked
Joined: Feb 2007
Posts: 50,271
Likes: 5,822
From: S/W Missouri, Polk county
Club FTE Gold Member
Sheet 2 has the dual tanks on the far R/H side in the middle. Sorry to hear that "painless" is not so true.





Reply
0
Old Sep 14, 2020 | 03:58 PM
Share
  #3
77ford250's Avatar
77ford250
Thread Starter
|
Mountain Pass
Joined: Jul 2020
Posts: 155
Likes: 7
I appreciate it after reading it and looking it over I got it thank you
