Part number HELP !
I have a 1966 F350/352/NP435/2wd. Looking for motor mounts.
It has one front mount TFAA-6039-1 UPPER
CITT-6038-B LOWER piece. The two bell housing mounts have two numbers on them C5TA-6068-L-green AND C4TA-6068-A-YELLOW.
Looking at NPD shows a confusing array of choices with basic part numbers, mostly for the back mounts.Looks like the front is straight forward using the part numbers F-6038-14 AND T-6039-1. The rear does not show my truck and many choices with part numbers F-6068-1/2/3/4. Closest seems to be a F100-250 4by2 65 to 67 F-6068-2. Need to order these ASAP as my new motor comes in two weeks.
It has one front mount TFAA-6039-1 UPPER
CITT-6038-B LOWER piece. The two bell housing mounts have two numbers on them C5TA-6068-L-green AND C4TA-6068-A-YELLOW.
Looking at NPD shows a confusing array of choices with basic part numbers, mostly for the back mounts.Looks like the front is straight forward using the part numbers F-6038-14 AND T-6039-1. The rear does not show my truck and many choices with part numbers F-6068-1/2/3/4. Closest seems to be a F100-250 4by2 65 to 67 F-6068-2. Need to order these ASAP as my new motor comes in two weeks.
Ford Parts Specialist
Joined: Nov 2006
Posts: 88,826
Likes: 787
From: Simi Valley, CA
You are unaware of the quantity of the mounts. There is 1 upper and 1 lower front. 2 upper and 2 lower rear (see pics).
352: These parts are the same: 1965 F100/250 4WD - 1965/66 F350 - 1966 F250 4WD
The numbers marked on your mounts are ID numbers, not part numbers.
From the 1964/72 Ford Truck Parts Catalog - Text section 60.7:
TFAA-6038-A .. Upper Front Insulator-Rectangular / Obsolete
MILLER OBSOLETE PARTS in Binghamton NY has 6 = 607-722-5371.
GREEN SALES CO. in Cincinnati OH has 23 = 800-543-4959 / 513-731-3304.
--------------------------------------------------------------------------------------
TFAA-6039-A .. Lower Front Insulator-Round / Obsolete
MILLER OBSOLETE PARTS has 16.
---------------------------------------
C1TT-6A061-D .. R & L Lower Rear Insulator-Round / Obsolete
GREEN SALES CO. has 66.
------------------------------
C1TT-6068-C .. R & L Upper Rear Insulator-Rectangular / Obsolete
AL WHITE MOTORS in Manchester TN has 1 = 931-728-9700.
No other Ford dealer, no obsolete parts vendor has any.
352 = Upper parts catalog pics at center and right:
352: These parts are the same: 1965 F100/250 4WD - 1965/66 F350 - 1966 F250 4WD
The numbers marked on your mounts are ID numbers, not part numbers.
From the 1964/72 Ford Truck Parts Catalog - Text section 60.7:
TFAA-6038-A .. Upper Front Insulator-Rectangular / Obsolete
MILLER OBSOLETE PARTS in Binghamton NY has 6 = 607-722-5371.
GREEN SALES CO. in Cincinnati OH has 23 = 800-543-4959 / 513-731-3304.
--------------------------------------------------------------------------------------
TFAA-6039-A .. Lower Front Insulator-Round / Obsolete
MILLER OBSOLETE PARTS has 16.
---------------------------------------
C1TT-6A061-D .. R & L Lower Rear Insulator-Round / Obsolete
GREEN SALES CO. has 66.
------------------------------
C1TT-6068-C .. R & L Upper Rear Insulator-Rectangular / Obsolete
AL WHITE MOTORS in Manchester TN has 1 = 931-728-9700.
No other Ford dealer, no obsolete parts vendor has any.
352 = Upper parts catalog pics at center and right:
Thread Starter
|
Senior User
Joined: Apr 2014
Posts: 133
Likes: 1
SO if I can find mounts for a 1965 F100/250 4WD or 1965/66 F350 or 1966 F250 4WD I should be OK with the rear then. Looking at NPD I cannot find a match with the options above. Wonder what the difference is. Closest is a F100 4by4 66 to 67.
Ford Parts Specialist
Joined: Nov 2006
Posts: 88,826
Likes: 787
From: Simi Valley, CA
SO if I can find mounts for a 1965 F100/250 4WD or 1965/66 F350 or 1966 F250 4WD I should be OK with the rear then.
Looking at NPD I cannot find a match with the options above. Wonder what the difference is.
Dunno if NPD or anyone other repro parts seller has the correct mounts...or not.
Closest is F100 4WD 66 to 67.
Incorrect!
Looking at NPD I cannot find a match with the options above. Wonder what the difference is.
Dunno if NPD or anyone other repro parts seller has the correct mounts...or not.
Closest is F100 4WD 66 to 67.
Incorrect!
1976 was the last year that Ford offered the F100 with 4WD
For sources, see edited post #4.
