Ford Engine Oil Cooler Filter Adapter
#1
Ford Engine Oil Cooler Filter Adapter
I took a little break from working on my truck today and decided to dig out an old Ford oil cooler adapter, to piddle with and clean it up. I had found the adapter in a wrecking yard back in the mid-'90s.
It's for a 429 Cobra Jet/Super Cobra Jet (the number on the adapter is D1ZE-6881-AA) but, it'll bolt onto any Ford engine from a 170 six cylinder to a 460. --I see identical adapters on ebay, from time to time, going for $200.00-$350.00 dollars.
This is what the factory adapter-to-block gasket looks like.
I don't have that gasket so, I made my own out of teflon.
Some information on this factory oil cooler adapter as well as other factory oil coolers that Ford produced.
Oil Cooler
It's for a 429 Cobra Jet/Super Cobra Jet (the number on the adapter is D1ZE-6881-AA) but, it'll bolt onto any Ford engine from a 170 six cylinder to a 460. --I see identical adapters on ebay, from time to time, going for $200.00-$350.00 dollars.
This is what the factory adapter-to-block gasket looks like.
I don't have that gasket so, I made my own out of teflon.
Some information on this factory oil cooler adapter as well as other factory oil coolers that Ford produced.
Oil Cooler
#2
#3
Are all the gaskets still available for these?
#4
I also have a couple of other filter to block adapters.
I pulled this one off of an '80-'86 F-350 DRW with a 460. It isn't plumbed for an oil cooler. My guess is its main purpose was for engine to frame clearance by re-positioning the oil filter.
I pulled this one off of an '87 E-350 DRW Super Duty with a 460.
Unfortunately, part of the threaded boss is broken off. I have the piece that broke off but, I'm uncertain if it can be reattached.
All three adapters, side by side.
I pulled this one off of an '80-'86 F-350 DRW with a 460. It isn't plumbed for an oil cooler. My guess is its main purpose was for engine to frame clearance by re-positioning the oil filter.
I pulled this one off of an '87 E-350 DRW Super Duty with a 460.
Unfortunately, part of the threaded boss is broken off. I have the piece that broke off but, I'm uncertain if it can be reattached.
All three adapters, side by side.
#5
#6
I have a Ford plate type (better than fin type) automatic transmission cooler, on my '69 F-100, that I robbed from a '92 F-150. It measures 11" x 5-1/2" x 1-1/2".
This is the plate type engine oil cooler I had pulled from the '87 E-350 DRW Super Duty, (from the same vehicle I got one of the filter adapters from). It also measures 11" x 5-1/2" x 1-1/2". I plugged the ports, bead blasted and primed it today.
#7
Trending Topics
#8
I had forgotten about this one. This past summer, I found a 5.0L Explorer in my local wrecking yard and I pulled the GT40P heads off of it. While I was at it, I grabbed this water-to-oil heat exchanger off the engine.
#9
#12
Oil Cooler
#13
Gotta love previous owner's handy work (I'm being facetious here). I went to unscrew the oil filter fitting from the block and I couldn't get the socket to stay on it. --the hex of the fitting requires a 1-1/4" socket. After I shined the drop light over on it to get a good look, I could see why the socket didn't want to stay on.
My 1-1/4" socket is a 12-point. I couldn't get it to hold without slipping off so, I had to go to the parts store and buy a 6-point 1-1/4" socket. After I drove the new socket up on the mangled fitting with a hammer, I was finally able to break it loose and unscrew it from the block.
This is the reason my 12-point 1-1/4" socket wouldn't unscrew this fitting.
I don't understand what they (previous owner) thought they were trying to accomplish here --stop a leak?????? --which could have been possible since there's a film of red RTV on the filter seal mounting pad but, this fitting isn't something that's likely to leak. Either way, it doesn't make good sense for the fitting to have been messed with or to have put RTV on the filter mounting pad.
This is a comparison of the regular filter fitting on the left and the oil cooler adapter fitting on the right. --although, the hex of the fitting shouldn't be chewed up like this.
Later model Ford engines don't have the large 1-1/4" external hex on the oil filter fittings. The hex is inside the hole where the filter spins on. It requires a 7/16" Allen wrench to remove/install the later model filter fitting.
Later model filter fitting below.
My 1-1/4" socket is a 12-point. I couldn't get it to hold without slipping off so, I had to go to the parts store and buy a 6-point 1-1/4" socket. After I drove the new socket up on the mangled fitting with a hammer, I was finally able to break it loose and unscrew it from the block.
This is the reason my 12-point 1-1/4" socket wouldn't unscrew this fitting.
I don't understand what they (previous owner) thought they were trying to accomplish here --stop a leak?????? --which could have been possible since there's a film of red RTV on the filter seal mounting pad but, this fitting isn't something that's likely to leak. Either way, it doesn't make good sense for the fitting to have been messed with or to have put RTV on the filter mounting pad.
This is a comparison of the regular filter fitting on the left and the oil cooler adapter fitting on the right. --although, the hex of the fitting shouldn't be chewed up like this.
Later model Ford engines don't have the large 1-1/4" external hex on the oil filter fittings. The hex is inside the hole where the filter spins on. It requires a 7/16" Allen wrench to remove/install the later model filter fitting.
Later model filter fitting below.
