2018 F450 Schematic
Thread Starter
|
Tuned
Joined: Dec 2012
Posts: 345
Likes: 2
2018 F450 Schematic
Hello everyone, i am looking for some schematics for my 2018 F450, i am needing to find a keyed 12V source and wire color for the horn wire that is in the column. Also there seemed to be a lot of talk on the different places that the wires for the up fitters switches came in the cab...... has this verified as too where they are a t??
Thanks Pat
Thanks Pat
Logistics Pro
Joined: Apr 2000
Posts: 4,334
Likes: 306
From: Mills River
Pat,
There’s a keyed +12V source (“hot on start/run”) in the upfitter switch wire bundle located under the U/S relay box. The linked bulletin contains detailed info.
I can’t help with the horn circuit.
Regards,
Jim / crewzer
https://madocumentupload.marketingas...1fb63&v5=False
There’s a keyed +12V source (“hot on start/run”) in the upfitter switch wire bundle located under the U/S relay box. The linked bulletin contains detailed info.
I can’t help with the horn circuit.
Regards,
Jim / crewzer
https://madocumentupload.marketingas...1fb63&v5=False
