What do y'all think?
Thread Starter
|
Senior User
Joined: Apr 2014
Posts: 252
Likes: 0
What do y'all think?
So this is my first FE / ford truck.04-30-2014 06:10 PM by GaRedneck91
My rig is a 75 ford f100 had the 360 which is being took out and rebuilt and converted to the 390. I'm swapping the old intake for the edelbrock performer and the carb for a holley 750 vac secondary's.I decided to go with the edelbrock performer plus cam. Money allowing headers soon .. Got 3:50 gears and 33x12.50x15 m/t . It has the 4speed granny 1st.I use my truck for everything from huntin to hittin mud holes to just crusin to haulin scrap or whatever I need it for. The cam specs are:
Duration Advertised 272° Intake/282° Exhaust
Duration @ .050'' 194° Intake/204° Exhaust
Lift @ Valve .460'' Intake/.480'' Exhaust
Lift @ Cam .265'' Intake/.280'' Exhaust
Lobe Separation Angle 110°
Intake Centerline 105°
Intake Timing @ .050" Open 8° ATDC
Close 22° ABDC
Exhaust Timing @ .050" Open 37° BBDC
Close 13° BTDC
I was just wonder what y'all thought about this little setup and if y'all had anything to add before I start my rebuild. Also everything else not mentioned is stock just bored .030 over.
My rig is a 75 ford f100 had the 360 which is being took out and rebuilt and converted to the 390. I'm swapping the old intake for the edelbrock performer and the carb for a holley 750 vac secondary's.I decided to go with the edelbrock performer plus cam. Money allowing headers soon .. Got 3:50 gears and 33x12.50x15 m/t . It has the 4speed granny 1st.I use my truck for everything from huntin to hittin mud holes to just crusin to haulin scrap or whatever I need it for. The cam specs are:
Duration Advertised 272° Intake/282° Exhaust
Duration @ .050'' 194° Intake/204° Exhaust
Lift @ Valve .460'' Intake/.480'' Exhaust
Lift @ Cam .265'' Intake/.280'' Exhaust
Lobe Separation Angle 110°
Intake Centerline 105°
Intake Timing @ .050" Open 8° ATDC
Close 22° ABDC
Exhaust Timing @ .050" Open 37° BBDC
Close 13° BTDC
I was just wonder what y'all thought about this little setup and if y'all had anything to add before I start my rebuild. Also everything else not mentioned is stock just bored .030 over.
Mountain Pass
Joined: May 2013
Posts: 131
Likes: 0
From: Spanish Springs
Hello Mike,
Where can I find out more about DD5? Is that simulation software?
Thanks
Byron
Where can I find out more about DD5? Is that simulation software?
Thanks
Byron
Trending Topics
Cargo Master
Joined: Sep 2012
Posts: 3,061
Likes: 39
From: Laramie, WY
Mikes 68 F100 has helped me a lot and done plenty of dyno simulations for others here. I think he is using this:
DeskTop Dyno5 Main Page
DeskTop Dyno5 Main Page
FTE Stories
Ford Trucks for Ford Truck Enthusiasts
AEV FXL Super Duty - the Super Duty Raptor Ford Doesn't Make
Brett Foote
Lobo Vs Lobo: Proof the F-150 Lobo Should Be Even Lower!
Michael S. Palmer
Ford's 2001 Explorer Sportsman Concept Looks For a New Home
Verdad Gallardo
10 Best Ford Truck Engines We Miss the Most!
Joe Kucinski
2026 Shelby F-150 Off-Road: Better Than a Raptor R?
Brett Foote
2027 Super Duty Carhartt Package First Look: 12 Things You NEED to Know!
Michael S. Palmer
10 Most Surprising 2026 Ford Truck Features!
Joe Kucinski
Top 10 Ford Trucks Coming to Mecum Indy 2026
Brett Foote
5 Best / 5 Worst Ford Truck Wheels of All Time
Joe Kucinski
Logistics Pro
Joined: Jan 2011
Posts: 4,762
Likes: 54
From: Antelope Valley ,CA
Turbo dog is right , you can get it on Amazon $49.00 money well spent if you are building a motor and not sure on parts to buy .
there's a shh free download link out there , but I wouldn't do it , most likely a VIRUS
there's a shh free download link out there , but I wouldn't do it , most likely a VIRUS
